WIDE BAND, RF AND BALUN TRANSFORMERS
ABT-6-XXX
| | | | | | | | | | | | | | |
FEATURES:
• Mini Ceramic Base
• High Reliability
• Extended Temperature
• RoHS Compliance
OPTIONS:
• Tape and Reel is standard
• Custom design available
APPLICATIONS:
• RF, Set Top Box, Cable Modem
• Cable TV, Wide Band RF Applicants
• Balance to Unbalance application
• RF signal monitor point
STANDARD SPECIFICATIONS:
Part No
ABT-6-
Turns
Operating
Frequency
MHz
Insertion
Loss
dB Max
Figure
OUTLINE DRAWING:
Double Balanced Mixer (200Ω:50Ω)
2½
3
4-1500
2A
3½
3
3-1200
3A
4½
3
1.5-1000
4A
5½
2
5-500
5A
2½
4
400-1300
6A
Frequency Mixer (200Ω:50Ω)
2:2:2
3
6-400
2B
3:3:3
3
3-350
3B
4:4:4
3
2-250
4B
5:5:5
3
1-200
5B
Balun Transformer (50Ω:50Ω)
2½
3
2.5-600
2C
3½
3
18-1800
3C
4½
3
1-1300
4C
5½
3
0.8-1300
5C
Power Distributor/Combiners (50Ω:100Ω)
6-1800
1-2:2-3:4-5:5-6
in-out1,2=5dB
2E
1:3:2:2
out1-out2=13dB
5-1900
1:4:3:3
in-out1,2=5dB
3E
out1-out2=13dB
in-out1,2=5dB
2-1000
1:3:2:2
4E
out1-out2=12dB
in-out1,2=4dB
2-400
1:4:2:2
5E
out1-out2=15dB
Directional Coupler (50Ω:50Ω)
50-1500
2½
in-out1, 2dB
2F
in-out2, 10dB
10-2000
in-out1, 2dB
3½
3F
in-out2, 12dB
in-out1, 1.5dB
8-1200
4½
4F
in-ou2t, 14dB
in-out1, 1.2dB
5-1000
5½
5F
in-out2, 15dB
rev2.1-6/05
A
A
A
A
A
B
B
B
B
C
C
C
C
E
3
4
3
4
FIGURE (WIRE CONNECTION):
A
1
6
1
B
6
2
2
E
E
E
1
In
2
Out1
C
1
6
2
3
4
E
6
1
In
2
Out2
4
Out2
3
F
1
6
Out1
F
F
F
F
3
1
4
Dimensions: inch/mm
TECHNICAL INFORMATION:
• Ordering Code: ABT-XX(Size)-XX(P/N)
• Add-T for tape and reel
• Insulation Resistance: 10MΩ minimum
• See SCD or detail E&M performance
• Operating Temperature: -40°C to +85°C
All specifications subject to change without notice.
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
