NKE Series
Input
Voltage
1 Watt Single Output
Output
Output
Efficiency
Model
Voltage
Current
Number
3.3 V
303 mA
75%
NKE0303S
3.3 V
5.0 V
200 mA
76%
NKE0305S
3.3 V
303 mA
75%
NKE0503S
5.0 V
200 mA
69%
NKE0505S
5V
9.0 V
111 mA
77%
NKE0509S
12.0 V
83 mA
78%
NKE0512S
15.0 V
66 mA
80%
NKE0515S
5.0 V
200 mA
71%
NKE1205S
9.0 V
111 mA
77%
NKE1209S
12 V
12.0 V
83 mA
78%
NKE1212S
15.0 V
66 mA
80%
NKE1215S
NOTE: For DIP package replace ‘S’ at end of model number with ‘D’.
Input
●
Input Range
●
Reflected Ripple Current
●
No Load Power Consumption
±10% of nominal
60 mA pk-pk max
150 mW typical
-7.5% to 2.5% typical at full load
1.2% max
15.0% max 3.3 V & 5 V models
10.0% max 9 V models
9.5% max 12 V models
8.5% max 15 V models
0.03%/°C
<80 mV pk-pk 3.3 V models
<100 mV pk-pk 5 V models
<90 mV pk-pk 9 V models
<65 mV pk-pk 12 V models
<55mV pk-pk 15 V models
1s
-40 °C to 85 °C
-50 °C to 130 °C
3000 V DC
115 kHz
300 °C/10 s 1.5 mm from case
Output
●
Voltage Accuracy of Nom.
●
Line Regulation (Vin ±10%)
●
Load Regulation
(10%-100%)
●
Temperature Coefficient
●
Ripple & Noise
(20 MHz Bandwidth)
●
Short Circuit Duration
General
●
Operating Temperature
●
Storage Temperature
●
Isolation
(Flash Tested for 1 sec)
●
Switching Frequency
●
Lead Temp
All pins on a 2.54 mm pitch and within a ø0.25 mm of true pin pitch position.
All dimensions in mm xx.xx ±0.25 mm
Weight : 1.03 g
