SR7820
Series
Low Cost, 2A Output
Non-isolated POL
Switching Regulators
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
Efficiency to 92%
•
2A Output Current
•
Compact SIP Case
•
LM78xx Replacement
•
Wide Input Range
•
Short Circuit Protected
•
Thermal Shutdown
•
Low Noise
•
Low Low Cost
Output
Parameter
Output Voltage Accuracy
Line Regulation
Load Regulation
Ripple & Noise (20 MHz)
Thermal Shutdown
Quiescent Current
Temperature Coefficient
Maximum Capacitive Load
Output Current Limit
Short Circuit Input Power
Output Short Circuit
Conditions
Vin = Min to Max
Iout = 10% to 100%
See Note 2
See Note 3
Min.
Typ.
±2.0
±0.5
±0.5
25
150
5
Max.
±3.0
±0.75
±1.0
45
10
0.03
1,000
1.8
5,000
0.5
Continuous (Autorecovery)
Conditions
Min.
Not Isolated
280
Min.
-40
-55
1.5 mm From Case For 10 Sec
Free Air Convection
RH, Non-condensing
Typ.
330
Typ.
+25
Units
%
%
%
mV P - P
°C
mA
%/°C
µF
mA
W
General
Parameter
Isolation Voltage
Switching Frequency
Max.
450
Max.
+85
+100
+125
300
95
Units
kHz
Units
°C
°C
°C
°C
%
Environmental
Parameter
Operating Temperature Range
Operating Temperature Range
Storage Temperature Range
Lead Temperature
Cooling
Humidity
Physical
Case Size
Case Material
Weight
Conditions
Ambient
Case
0.45 x 0.35 x 0.69 Inches (11.5 x 9.0 x 17.50 mm)
Non-Conductive Black Plastic (UL-94V0)
0.13 Oz (3.7g)
Conditions
MIL HDBK 217F, 25°C, Gnd Benign
Min.
2.0
Typ.
Max.
Units
MHours
Reliability Specifications
Parameter
MTBF
Typical Application Circuit
Component Values
Model
Number
Capacitors
C
2
, C
4
C
1
, C
3
(µF/V)
(µF/V)
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
SR7820-015W
SR7820-018W
SR7820-02W
SR7820-03W
SR7820-05W
SR7820-06W
10 /25
10 /25
10 /25
10 /25
10 /25
10 /25
22 / 6.3
22 / 6.3
22 / 6.3
22 / 6.3
22 / 16
22 / 16
Notes:
1. C1 is a low ESR ceramic capacitor used to minimize noise at the regulator.
A tantalum or low ESR electrolytic capacitor may also be used.
2. C1 & C2 are required and should be mounted as close to the regulator pins as possible.
www.micropowerdirect.com
Model Selection Guide
Output
Input
Efficiency (%, Typ)
Voltage Range Voltage Current
(VDC)
(VDC) (mA, Max)
Min Vin Max Vin
SR7820-015W(L)
4.75 - 18.0
1.5
2,000.0
79
76
SR7820-018W(L)
4.75 - 18.0
1.8
2,000.0
81
79
SR7820-02W(L)
4.75 - 18.0
2.5
2,000.0
85
83
SR7820-03W(L)
4.75 - 18.0
3.3
2,000.0
87
86
SR7820-05W(L)
7.00 - 18.0
5.0
2,000.0
91
88
SR7820-06W(L)
8.50 - 18.0
6.5
2,000.0
92
91
Model
Number
For right-angle pin option, add suffix “L” to model number (i.e.
SR7820-05WL)
Notes:
1. Load regulation is specified for an output load change of 10% to 100%.
2. Measured at an internal IC junction.
3. Quiescent current is specified at 0% load for Vin = min to max.
4. This regulator is not designed to be used in parallel with another unit to increase output power.
5. The input should not exceed the range given in the model selection chart. Exceeding this limit could
damage the unit.
www.micropowerdirect.com
Derating Curve
Mechanical Dimensions
Characteristic Curves
(Efficiency & Ripple)
Efficiency vs Input Voltage (Full Load)
Efficiency vs Load (Vin = Nom)
Ripple vs Load (Vin = Nom)
Pin Connection
Pin
Function
1
+Vin
2
Gnd
3
+Vout
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx = ±0.01 (±0.25)
•
Pin 1 is marked by a “dot” or indentation on the side of the unit
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
Ripple vs Input Voltage (Full Load)
FAX: (781) 344-8481
•
TEL: (781) 344-8226
•
E-Mail: sales@micropowerdirect.com
