SINE OUTPUT, 5VDC, FULL-SIZE DIP
CRYSTAL CLOCK OSCILLATORS
ACOS
FEATURES:
• Wide Frequency Range.
• Anti-Static Packaging Tube.
• Sine wave output.
• Low harmonic distortion.
APPLICATIONS:
• Provide clock signals for microprocessors and digital circuits.
• High Output drive capability applications.
• Great for low EMI applications.
STANDARD SPECIFICATIONS
Frequency Range
Frequency Range
Operation Mode
Operating Temperature
Operating Temperature
Storage Temperature
Storage Temperature
Frequency Stability
Frequency Tolerance
@
25°C
Supply Voltage
Frequency Stability over Temp.
Output load
Equivalent Series Resistance
Output power
(ESR) Maximum
3.5 MHz - 25
- 40 MHz
8 MHz
MHz
Fundamental,
(see
0°C to + 70°C
AT
options)
-10°C
-55°C to
C
(See Options)
to + 60°
+125°C
-55°C to + 125° C
± 100 ppm max.
(See Options)
± 50 ppm max.
(See Options)
5.0 Vdc ± 10%
± 50 ppm max.
(See Options)
50W
200
W
for 3.5 MHz < F < 4.0 MHz
0dBm min.
150
W
for 4.0 MHz < F < 6.0 MHz
-25dBc min.
100
W
for 6.0 MHz < F < 10.0 MHz
80
W
for 10 MHz < F < 14.0 MHz
± 5ppm/yr. max.
_
50
W
for 14 MHz < F < 25 MHz
Harmonics
Aging
Please see environmental, and mechanical specifications Group 1.
Dimensions: Inches (mm)
ORDERING OPTIONS
ACOS - Frequency - Temperature - Overall Frequency Stability - Value Added
XX.XXXXMhz
-G
Gull Wing
-QXX (Trimmed Leads)
PIN
NUMBER
FUNCTION
1
7
8
14
NC
GND / Case
Output
V
cc
-D for -10°C
-E for -20°C
-F for -30°C
-N for -30°C
-L for -40°C
to + 60°C
to + 70°C
to + 70°C
to + 85°C
to + 85°C
-R
-K
-H
-C
for ± 25 ppm max
for ± 30 ppm max
for ± 35 ppm max
for ± 50 ppm max
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
NOTE: Left blank if standard
•
All specifications and markings subject to change without notice
29 Journey • Aliso Viejo, CA 92656 • USA
(949) 448-7070 •
F
AX
: (949) 448-8484
E-
MAIL
:
abinfo
@
abracon.com •
I
NTERNET
A
DDRESS
:
www.abracon.com
®
