LX1431IM: DescriptionTwo Terminal Voltage Reference, 1 Output, 5V, BIPolar, PDIP8,; CategoryPower/power management The power supply circuit; File Size402KB，7 Pages; ManufacturerLinfinity Microelectronics

Download Datasheet Parametric Compare View All

LX1431IM Overview

Two Terminal Voltage Reference, 1 Output, 5V, BIPolar, PDIP8,

LX1431IM Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Linfinity Microelectronics
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	TWO TERMINAL VOLTAGE REFERENCE
JESD-30 code	R-PDIP-T8
JESD-609 code	e0
Number of functions	1
Output times	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	0.1 A
Maximum output voltage	5.05 V
Minimum output voltage	4.95 V
Nominal output voltage	5 V
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP8,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Maximum supply current (Isup)	0.012 mA
Maximum supply voltage (Vsup)	2.51 V
Minimum supply voltage (Vsup)	2.4 V
surface mount	NO
technology	BIPOLAR
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Fine-tuning/adjustable output	NO
