IR9494 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> IR9494

IR9494: DescriptionSwitching Regulator, 0.25A, 300kHz Switching Freq-Max, PDIP16, DIP-16; CategoryPower/power management The power supply circuit; File Size82KB，1 Pages; ManufacturerSHARP; Websitehttp://sharp-world.com/products/device/

Download Datasheet Parametric Compare View All

IR9494 Overview

Switching Regulator, 0.25A, 300kHz Switching Freq-Max, PDIP16, DIP-16

IR9494 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	SHARP
package instruction	DIP,
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR
Control Technology	PULSE WIDTH MODULATION
JESD-30 code	R-PDIP-T16
JESD-609 code	e0
length	19.25 mm
Number of functions	1
Number of terminals	16
Maximum output current	0.25 A
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
surface mount	NO
Maximum switching frequency	300 kHz
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm

Preview

Download Datasheet

View All

IR9494 Related Products

	IR9494	IR3M01	IR3M03AN	IR3M04	IR3M04N	IR9494N	IR3M03A
Description	Switching Regulator, 0.25A, 300kHz Switching Freq-Max, PDIP16, DIP-16	Switching Regulator, 0.1A, 200kHz Switching Freq-Max, PDIP16, DIP-16	Switching Regulator, 1.5A, 100kHz Switching Freq-Max, PDSO8, SOP-8	Switching Regulator, 0.02A, 500kHz Switching Freq-Max, PDIP8, DIP-8	Switching Regulator, 0.02A, 500kHz Switching Freq-Max, PDSO14, SOP-14	Switching Regulator, 0.25A, 300kHz Switching Freq-Max, PDSO16, SOP-16	Switching Regulator, 1.8A, 100kHz Switching Freq-Max, PDIP8, DIP-8
package instruction	DIP,	DIP-16	SOP,	DIP-8	SOP-14	SOP-16	DIP-8
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR
JESD-30 code	R-PDIP-T16	R-PDIP-T16	R-PDSO-G8	R-PDIP-T8	R-PDSO-G14	R-PDSO-G16	R-PDIP-T8
length	19.25 mm	19.25 mm	5 mm	9.1 mm	10 mm	10 mm	9.1 mm
Number of functions	1	1	1	1	1	1	1
Number of terminals	16	16	8	8	14	16	8
Maximum output current	0.25 A	0.1 A	1.5 A	0.02 A	0.02 A	0.25 A	1.8 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	DIP	SOP	DIP	SOP	SOP	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	SMALL OUTLINE	IN-LINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	YES	NO	YES	YES	NO
Maximum switching frequency	300 kHz	200 kHz	100 kHz	500 kHz	500 kHz	300 kHz	100 kHz
Terminal form	THROUGH-HOLE	THROUGH-HOLE	GULL WING	THROUGH-HOLE	GULL WING	GULL WING	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	1.27 mm	2.54 mm	1.27 mm	1.27 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
width	7.62 mm	7.62 mm	4.4 mm	7.62 mm	4.4 mm	4.4 mm	7.62 mm
Control Technology	PULSE WIDTH MODULATION	PULSE WIDTH MODULATION	-	PULSE WIDTH MODULATION	PULSE WIDTH MODULATION	PULSE WIDTH MODULATION	-
Base Number Matches	-	1	1	1	1	1	-
