Clock Oscillators Surface Mount Type
KC5032D Series (FXO-61F2 Series)
CMOS/ 3.3V/ 5.0V/ 5.0×3.2mm
Features
• Compact and low profile (5×3.2×1.2mm)
• Surface mount type suitable for auto
pick-and-place
• Reflow soldering compatible
• CMOS, TTL IC direct drive is possible
• With tri-state function
• Supply voltage V
CC
=3.3/
5.0V available
How to Order
KC5032D 25.0000 C 3 1 B 00
①
②
③④⑤⑥ ⑦
Frequency Tolerance (Overall)
Operating
Freq. Tol.
Note
−
6
Temperature
Code
×
10
Range (°C)
±100
1
1.8 to 50MHz
−10
to
+70
±
50
0
(standard) 1.8 to 32MHz
±
30
S
①
Type
②
Output Frequency
③
Output Type (CMOS)
④
Supply Voltage 5=5.0V, 3=3.3V
⑤
Frequency Tolerance (See table at left)
⑥
Symmetry/ INH Function
A: 40/ 60%, Disable
B: 40/ 60%, Stand-by
⑦
Customer Special Model Suffix
(STD Specification is “00”)
RoHS Compliant
Symmetry/ INH Function
Freq.
(MHz)
1.8 to 50
Code
KC5032D-C5 KC5032D-C3
A
B
Specifications
Item
Output Frequency Range
Frequency Tolerance (Overall)
Storage Temperature Range
Operating Temperature Range
Max. Supply Voltage
Supply Voltage
Current Consumption
Stand-by/ Disable Current
Symmetry
Rise/ Fall Time
Low Level Output Voltage
High Level Output Voltage
CMOS Load
Input Voltage Range
Low Level Input Voltage
High Level Input Voltage
Disable Time
Enable Time
Start-up Time
Symbol
fo
f
_tol
T
_stg
T
_use
—
V
CC
I
CC
I
_std
SYM
tr/ tf
V
OL
V
OH
L_CMOS
V
IN
V
IL
V
IH
t
_dis
t
_ena
t
_str
Conditions
KC5032Dxx.xxxxC5xA00 (FXO-61F2)
KC5032Dxx.xxxxC3xB00 (FXO-61FL2)
1.8 to 50
±30
(to 32MHz)
±50
(to 32MHz)
±100
(to 50MHz)
−40
to
+85
−10
to
+70
7 max.
5±0.5
3.3±0.3
18 max. (1.8 to 39.9MHz)
25 max.
25 max. (40 to 50MHz)
10 max.
40 to 60@50%V
CC
10 max.
10% V
CC
max.
90% V
CC
min.
15 max.
20 max.
0 to V
CC
0 to V
CC
0.8 max.
0.3 max.
2.2 min.
2.2 min.
150 max.
5 max.
10 max.
Units
MHz
×10
−
6
°C
°C
V
V
mA
µA
%
ns
V
V
pF
V
V
V
ns
ms
ms
Note: All electrical characteristics are defined at the maximum load and operating temperature range.
Please contact us for inquiry about operating temperature range, available frequencies and other conditions.
Dimensions
+
±
(Unit: mm)
Recommended Land Pattern
2.5
1.5
(Unit: mm)
2.5
1.6
Note: A capacitor of value 0.01 F between V
CC
and GND is recommended.
