Z8F2480PJ020EC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> Z8F2480PJ020EC

Z8F2480PJ020EC: DescriptionMicrocontroller, 8-Bit, FLASH, 20MHz, CMOS, PDIP28, PLASTIC, DIP-28; CategoryThe embedded processor and controller Microcontrollers and processors; File Size6MB，409 Pages; ManufacturerIXYS

Download Datasheet Parametric View All

Z8F2480PJ020EC Overview

Microcontroller, 8-Bit, FLASH, 20MHz, CMOS, PDIP28, PLASTIC, DIP-28

Z8F2480PJ020EC Parametric

Parameter Name	Attribute value
Maker	IXYS
Parts packaging code	DIP
package instruction	PLASTIC, DIP-28
Contacts	28
Reach Compliance Code	compliant
Has ADC	YES
Address bus width
bit size	8
maximum clock frequency	20 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PDIP-T28
length	36.96 mm
Number of I/O lines	23
Number of terminals	28
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
ROM programmability	FLASH
Maximum seat height	5.21 mm
speed	20 MHz
Maximum supply voltage	3.6 V
Minimum supply voltage	1.8 V
Nominal supply voltage	2.7 V
surface mount	NO
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	15.24 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

Z8 Encore! XP

F1680 Series

Advance Product Specification
