ISDN CO splitter for standard ADSL / VDSL2 applications
LPF compliant with ETSI specification TS 101-952-1-3,
v1.1.1 for both 2B1Q and 4B3T applications
Part of a standard series which has footprint compatibility
For ADSL, ADSL2+, VDSL and VDSL2 applications
RoHS-6 compatible
Patented technology: US7598837, US7598839,
CN1667763, EP1644943, TWI316724, CA2531599
Electrical Specifications @ 25°C
PARAMETER
ISDN Impedance
ISDN Insertion Loss 2B1Q
ISDN Return Loss 2B1Q
ISDN Insertion Loss 4B3T
ISDN Return Loss 4B3T
FREQUENCY
1 kHz to 80 kHz
1 kHz to 40 kHz
40 kHz to 80 kHz
1 kHz to 40 kHz
40 kHz to 80 kHz
1 kHz to 60 kHz
60 kHz to 80 kHz
1 kHz to 60 kHz
60 kHz to 60 kHz
30 kHz to 85 kHz
120 kHz to 1.1 MHz
1.1 MHz to 30 MHz
150 kHz to 1.1 MHz
1.1 MHz to 30 MHz
135
& 150
0.8 dB MAX
2.0 dB MAX
16 dB MIN
14 dB MIN
0.8 dB MAX
2.0 dB MAX
16 dB MIN
14 dB MIN
46 dB MIN
46 dB MIN
45 dB MIN
65 dB MIN
55 dB MIN
60 mA MAX
4.8
MAX
Longitudinal Balance
xDSL Insertion Loss
DC Current
Total DC Resistance
Mechanical
B8842NL
Weight . . . . . . . . . 8.0 grams
Tray. . . . . . . . . . . . . . . 80/tray
Inches
Dimensions:
mm
Unless otherwise specified, all
tolerances are ± .010
0,25
USA 858 674 8100
Germany 49 7032 7806 0
Singapore 65 6287 8998
Shanghai
86 21 62787060
China 86 755 33966678
Taiwan 886 3 4356768
www.pulseeng.com
1
B705.B (3/10)
XDSL SPLITTER FILTER MODULE
B8842NL
SmartER Series
Schematic
B8842NL
