BX2303WA: DescriptionTelecom Transformer; CategoryPower management transformer; File Size555KB，2 Pages; ManufacturerPulse Electronics

Download Datasheet Parametric Compare View All

BX2303WA Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BX2303WA	-	-	View	Buy Now

BX2303WA Overview

Telecom Transformer

BX2303WA Parametric

Parameter Name	Attribute value
Maker	Pulse Electronics
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	TURNS RATIO: 1.4:1, COMPATIBLE WITH BLADERUNNER CENTRAL OFFICE BCM6410; BCM6420 CHIPSETS
high	10.7 mm
length	9.8 mm
Manufacturer's serial number	BX2303WA
Installation features	SURFACE MOUNT
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
method of packing	TRAY
physical size	L9.8XB9.1XH10.7 (mm)
surface mount	YES
Transformer type	TELECOM TRANSFORMER
width	9.1 mm

Preview

Download Datasheet

View All

ADSL Line Transfomer

For Broadcom Bladerunner CO Chipset

Approved by Broadcom for use with Bladerunner

Central Office BCM6410 and BCM6420 chipsets

ADSL/POTS and ADSL/ISDN options available

for Broadcom approved Line Drivers

Compact footprint for high density Central Office

board layouts

Electrical Specifications @ 25°C - Operating Temperature -40°C to +85°C

Part

Number

1

BX2303WA

BX2302WA

BX2619W

BX2644L

1

Turns

Ratio

(Line:Chip)

1.4:1

1.2:1

OCL

Line

(μH

±5%)

100

410

430

420

Isolation

Voltage

(Vrms)

1500

THD

(dB MIN)

-80

Transformers are shipped in trays, unless Tape & Reel packaging is specified by adding the suffix “T” to this part number (BX2303WAT).

Mechanical

BX2644L

Schematic

Weight

......................1.4 grams

Tube

............................350/tube

Inches

Dimensions:

mm

Unless otherwise specified,

all tolerances are

±

.004

0,10

USA 858 674 8100

1

Germany 49 7032 7806 0

Singapore 65 6287 8998

Shanghai 86 21 62787060

China 86 755 33966678

Taiwan 886 3 4356768

B811.C (02/12)

pulseelectronics.com

BX2303WA Related Products

	BX2303WA	BX2619W	BX2644L	BX2644LT	BX2303WAT
Description	Telecom Transformer	Telecom Transformer	Telecom Transformer	Telecom Transformer	Telecom Transformer
Maker	Pulse Electronics	Pulse Electronics	Pulse Electronics	Pulse Electronics	Pulse Electronics
Reach Compliance Code	unknown	unknown	unknown	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99
Other features	TURNS RATIO: 1.4:1, COMPATIBLE WITH BLADERUNNER CENTRAL OFFICE BCM6410; BCM6420 CHIPSETS	TURNS RATIO: 1.2:1, COMPATIBLE WITH BLADERUNNER CENTRAL OFFICE BCM6410; BCM6420 CHIPSETS	TURNS RATIO: 1.2:1, COMPATIBLE WITH BLADERUNNER CENTRAL OFFICE BCM6410; BCM6420 CHIPSETS	TURNS RATIO: 1.2:1, COMPATIBLE WITH BLADERUNNER CENTRAL OFFICE BCM6410; BCM6420 CHIPSETS	TURNS RATIO: 1.4:1, COMPATIBLE WITH BLADERUNNER CENTRAL OFFICE BCM6410; BCM6420 CHIPSETS
high	10.7 mm	10.7 mm	9.3 mm	9.3 mm	10.7 mm
length	9.8 mm	9.8 mm	8 mm	8 mm	9.8 mm
Manufacturer's serial number	BX2303WA	BX2619W	BX2644L	BX2644L	BX2303WA
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
method of packing	TRAY	TRAY	TRAY	TAPE & REEL	TAPE & REEL
physical size	L9.8XB9.1XH10.7 (mm)	9.8mm X 9.1mm X 10.7mm	L8.0XB8.0XH9.3 (mm)	L8.0XB8.0XH9.3 (mm)	L9.8XB9.1XH10.7 (mm)
surface mount	YES	YES	YES	YES	YES
Transformer type	TELECOM TRANSFORMER	TELECOM TRANSFORMER	TELECOM TRANSFORMER	TELECOM TRANSFORMER	TELECOM TRANSFORMER
width	9.1 mm	9.1 mm	8 mm	8 mm	9.1 mm

Recommended Resources

USB interface circuit design of FT245BM and FPGA

AC voltmeter

Wanbao brand BYD-100H refrigerator circuit

LED backlight drive circuit diagram

lkHz literary bridge

Super audio induction heating power supply
