(Reference DP55D6S for Prime Rating Technical Data)
SYSTEM RATINGS
Standby
Voltage (L-L)
Phase
PF
Hz
kW
kVA
Amps
skVA@30%
Voltage Dip
Generator
Model*
Temp Rise
Connection
** UL 2200 Offered
DS60D6SGA
240V**
1
1.0
60
60
60
250
119
362CSL1604
130 °C/40 °C
12 LEAD
DOUBLE DELTA
DS60D6SDA
240V**
1
1.0
60
61
61
254
130
361CSL1613
130 °C/40 °C
4 LEAD
DS60D6SPA
208V**
3
0.8
60
63
78
218
200
361CSL1602
130 °C/40 °C
12 LEAD
LOW WYE
DS60D6SJA
240V**
3
0.8
60
63
78
189
200
361CSL1602
130 °C/40 °C
12 LEAD
HI DELTA
DS60D6SVA
380V**
3
0.8
60
60
75
114
266
361CSL1602
130 °C/40 °C
12 LEAD
HI WYE
DS60D6SRA
480V**
3
0.8
60
60
75
90
173
361CSL1601
130 °C/40 °C
12 LEAD
HI WYE
DS60D6SNA
600V**
3
0.8
60
60
75
72
136
361PSL1633
130 °C/40 °C
4 LEAD WYE
CERTIFICATIONS AND STANDARDS
//
//
Emissions –
EPA Tier 3 Certified
Generator set is designed and manufactured in
facilities certified to standards ISO 9001:2008 and
ISO 14001:2004
//
Performance Assurance Certification (PAC)
- Generator Set Tested to ISO 8528-5 for Transient Response
- Verified product design, quality and performance integrity
- All engine systems are prototype and factory tested
Power Rating
- Accepts Rated Load in One Step Per NFPA 110
//
//
UL 2200 / CSA – Optional
– UL 2200 Listed
– CSA Certified
2
/ /
/
DS60D6S
/
STANDARD FEATURES*
MTU Onsite Energy is a single source supplier
Global Product Support
2 Year Standard Warranty
4045HF280 Diesel Engine
- 4.5 Liter Displacement
- Mechanical Injection Pump
- 4-Cycle
//
Engine-generator resilient mounted
//
Complete Range of Accessories
//
//
//
//
Generator
- Brushless, Rotating Field Generator
- 2/3 Pitch Windings
- 300% Short Circuit Capability with Optional PMG
//
Digital Control Panel(s)
- UL Recognized, CSA Certified, NFPA 110
- Complete System Metering
- LCD Display
//
Cooling System
- Integral Set-Mounted
- Engine Driven Fan
//
STANDARD EQUIPMENT*
//
Engine
130 °C Maximum Standby Temperature Rise
1 Bearing, Sealed
Flexible Coupling
Full Amortisseur Windings
125% Rotor Balancing
3-Phase Voltage Sensing
100% of Rated Load - One Step
5% Maximum Total Harmonic Distortion
Air Cleaner
Oil Pump
Oil Drain Extension & S/O Valve
Full Flow Oil Filter
Fuel Filter with Water Separator
Jacket Water Pump
Thermostat
Blower Fan & Fan Drive
Radiator - Unit Mounted
Electric Starting Motor - 12V
Governor – Mechanical Droop
Base - Formed Steel
SAE Flywheel & Bell Housing
Charging Alternator - 12V
Battery Box & Cables
Flexible Fuel Connectors
Flexible Exhaust Connection
EPA Certified Engine
//
Digital Control Panel(s)
//
Generator
NEMA MG1, IEEE and ANSI standards compliance for temperature rise
and motor starting
Self-Ventilated and Drip-Proof
Superior Voltage Waveform
Solid State, Volts-per-Hertz Regulator
±1% Voltage Regulation No Load to Full Load
Brushless Alternator with Brushless Pilot Exciter
4 Pole, Rotating Field
Digital Metering
Engine Parameters
Generator Protection Functions
Engine Protection
Windows
®
-Based Software
Multilingual Capability
Remote Communications to RDP-110 Remote Annunciator
Programmable Contact Inputs
Programmable Contact Outputs
UL Recognized, CSA Certified, CE Approved
Event Recording
IP 54 Front Panel Rating with Integrated Gasket
NFPA110 Compatible
* Represents standard product only. Consult Factory/MTU Onsite Energy Distributor for additional configurations.
3
/ /
/
DS60D6S
/
APPLICATION DATA
//
Engine
John Deere
4045HF280
4-Cycle
4-Inline
4.5 (275)
10.6 (4.19)
12.7 (5.0)
19.0:1
1,800
Mechanical Droop
74 (99)
±0.50%
Dry
//
Fuel Consumption
STANDBY
19.3 (5.1)
14.8 (3.9)
10.6 (2.8)
Manufacturer
Model
Type
Arrangement
Displacement: L (in
3
)
Bore: cm (in)
Stroke: cm (in)
Compression Ratio
Rated RPM
Engine Governor
Maximum Power: kWm (bhp)
Speed Regulation
Air Cleaner
At 100% of Power Rating: L/hr (gal/hr)
At 75% of Power Rating: L/hr (gal/hr)
At 50% of Power Rating: L/hr (gal/hr)
//
Cooling - Radiator System
STANDBY
50 (122)
0.12 (0.5)
144 (38)
35 (1,979)
5 (278)
10.9 (619)
1.16 (1.55)
//
Liquid Capacity (Lubrication)
13 (3.4)
8.5 (2.3)
16.7 (4.4)
Ambient Capacity of Radiator: °C (°F)
Maximum Allowable Static
Pressure on Rad. Exhaust: kPa (in. H
2
0)
Water Pump Capacity: L/min (gpm)
Heat Rejection to Coolant: kW (BTUM)
Heat Rejection to Air to Air: kW (BTUM)
Heat Radiated to Ambient: kW (BTUM)
Fan Power: kW (hp)
Total Oil System: L (gal)
Engine Jacket Water Capacity: L (gal)
System Coolant Capacity: L (gal)
//
Air Requirements
STANDBY
5.4 (191)
91 (3,162)
//
Electrical
12
925
Electric Volts DC
Cold Cranking Amps Under -17.8 °C (0 °F)
//
Fuel System
3/8” NPT
3/8” NPT
1.8 (6)
Diesel #2
113 (29.9)
Aspirating: *m
3
/min (SCFM)
Air Flow Required for Rad.
Cooled Unit: *m
3
/min (SCFM)
Remote Cooled Applications;
Air Flow Required for Dissipation
of Radiated Gen-set Heat for a
Max of 25 °F Rise: *m
3
/min (SCFM)
* Air density = 1.184 kg/m
3
(0.0739 lbm/ft
3
)
//
40 (1,396)
Fuel Supply Connection Size
Fuel Return Connection Size
Maximum Fuel Lift: m (ft)
Recommended Fuel
Total Fuel Flow: L/hr (gal/hr)
Exhaust System
STANDBY
545 (1,013)
14.4 (508)
7.5 (30)
N/A
Gas Temp. (Stack): °C (°F)
Gas Volume at Stack
Temp: m
3
/min (CFM)
Maximum Allowable
Back Pressure: kPa (in. H
2
0)
Minimum Allowable
Back Pressure: kPa (in. H
2
0)
4
/ /
/
DS60D6S
/
WEIGHTS AND DIMENSIONS
Drawing above for illustration purposes only, based on standard open power 480 volt generator set. Lengths may vary with other voltages. Do not use for installation design. See website
Weights and dimensions are based on open power units and are estimates only. Consult the factory for accurate weights and dimensions for your specific generator set.
SOUND DATA
Unit Type
Level 0: Open Power Unit dB(A)
Standby Full Load
73
Sound data is provided at 7 m (23 ft). Generator set tested in accordance with ISO 8528-10 and with infinite exhaust.
EMISSIONS DATA
NO
x
3.2
HC
0.17
CO
0.7
PM
0.22
RATING DEFINITIONS AND CONDITIONS
Standby ratings apply to installations served by a reliable
utility source. The standby rating is applicable to varying
loads for the duration of a power outage. No overload
capability for this rating. Ratings are in accordance with
ISO 3046-1, BS 5514, AS 2789, and DIN 6271.
//
Deration Factor:
Altitude:
Consult your local MTU Onsite Energy Power
Generation Distributor for altitude derations.
Temperature:
Consult your local MTU Onsite Energy Power
Generation Distributor for temperature derations.
//
All units are in g/hp-hr and are EPA D2 cycle values.
Emission levels of the engine may vary as a function of ambient
temperature, barometric pressure, humidity, fuel type and
