FP6544PM Overview

RF AMPLIFIER MODEL

FP6544PM Parametric

Parameter Name	Attribute value
Maker	API Technologies
package instruction	FP-4
Reach Compliance Code	compli
Other features	I/P POWER-MAX (PEAK)=27DBM
structure	COMPONENT
Gain	10.5 dB
Maximum input power (CW)	13 dBm
Maximum operating frequency	500 MHz
Minimum operating frequency	10 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	WIDE BAND LOW POWER
Maximum voltage standing wave ratio	2

Preview

Download Datasheet

View All

RF AMPLIFIER

MODEL

TM6544PM

Features

!

Superior Phase Noise Performance

Low Noise Figure: 2 dB Typical

High IP3: +32 dBm Typical

Operating Temp. -55 ºC

to +85

ºC

TYPICAL

Ta= 25 ºC

10 - 500 MHz

12

+15

-15.5

<1.35:1

<1.5:1

2.0

+15

35

MIN/MAX

Ta = -55 ºC to +85 ºC

10 - 500 MHz

10.5 Min.

+13.0 Min.

-14.5 Max.

2.0:1 Max.

3.5 Max.

+15

38 Max.

Available as:

TM6544PM, 4 Pin TO-8 (T4)

TN6544PM, 4 Pin Surface Mount (SM3)

FP6544PM, 4 Pin Flatpack (FP4)

BX6544PM, Connectorized Housing (H1)

Typical Intermodulation Performance at 25 ºC

Second Order Harmonic Intercept Point ...... +52 dBm (Typ.)

Second Order Two Tone Intercept Point ....... +46 dBm (Typ.)

Third Order Two Tone Intercept Point ........... +32 dBm (Typ.)

Maximum Ratings

Ambient Operating Temperature ................ -55ºC to +100 ºC

Storage Temperature ................................. -62ºC to +125 ºC

Case Temperature .................................................. +125 ºC

DC Voltage .......................................................... +18 Volts

Continuous RF Input Power .................................. +13 dBm

Short Term RF Input Power ...... 50 Milliwatts (1 Minute Max.)

Maximum Peak Power .................... 0.5 Watt (3

µsec

Max.)

Specifications

CHARACTERISTIC

Frequency

Gain (dB)

Power @ 1 dB

Comp. (dBm)

Reverse

Isolation (dB)

In

Out

Noise Figure (dB)

Power

Vdc

mA

VSWR

Guaranteed Phase Noise Performance

(dBc/Hz)

Frequency

100 Hz

1 kHz

10 kHz

100 kHz

1 MHz

Typical

-157

-168

-170

-174

Guarantee (Min.)

-153

-164

-166

-170

Note: Care should always be taken to effectively ground the case of each unit.

Typical Performance Data

14

13

12

11

10

Start 10 MHz

Gain (dB)

0

-5

-10

-15

-20

Reverse Isolation (dB)

-130

-140

-150

-160

Start 10 MHz

Phase Noise (dBc/Hz)

+17

+16

+15

+14

+13

2.0

1.5

1.0

Start 10 MHz

1 dB Comp. (dBm)

Stop 500 MHz

Noise Figure (dB)

Stop 500 MHz

-170

-180

3

2

-190

100

1K

10K

100K

1M

1

Start 10 MHz

_________Guarantee __ __ __ __Typical

Start 10 MHz

Input VSWR

Stop 500 MHz

2.0

1.5

1.0

Stop 500 MHz

Output VSWR

Stop 500 MHz

Phase Noise Test Conditions:

Carrier Frequency: 200 MHz

Power Output: +15 dBm

Temperature: 25 ºC

Agilent ES5500 System

Stop 500 MHz

Start 10 MHz

Legend

+25 ºC

+85 ºC - - - - - - -55 ºC

Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, Florida 32905 · PH (888) 553-7531 · Fax (888) 553-7532

2/03/04

www.SpectrumMicrowave.com

Spectrum Microwave · 2707 Black Lake Place · Philadelphia, Pennsylvania 19154 · PH (215) 464-4000 · Fax (215) 464-4001

FP6544PM Related Products

	FP6544PM	BX6544PM	TM6544PM	TN6544PM
Description	RF AMPLIFIER MODEL	RF AMPLIFIER MODEL	RF AMPLIFIER MODEL	RF AMPLIFIER MODEL
Reach Compliance Code	compli	compliant	compli	compli
Other features	I/P POWER-MAX (PEAK)=27DBM	I/P POWER-MAX (PEAK)=27DBM	I/P POWER-MAX (PEAK)=27DBM	I/P POWER-MAX (PEAK)=27DBM
structure	COMPONENT	COAXIAL	COMPONENT	COMPONENT
Gain	10.5 dB	10.5 dB	10.5 dB	10.5 dB
Maximum input power (CW)	13 dBm	13 dBm	13 dBm	13 dBm
Maximum operating frequency	500 MHz	500 MHz	500 MHz	500 MHz
Minimum operating frequency	10 MHz	10 MHz	10 MHz	10 MHz
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C
RF/Microwave Device Types	WIDE BAND LOW POWER	WIDE BAND LOW POWER	WIDE BAND LOW POWER	WIDE BAND LOW POWER
Maximum voltage standing wave ratio	2	2	2	2
Maker	API Technologies	API Technologies	API Technologies	-
