1008 CHIP INDUCTORS
Aerospace Grade Chip Inductors
AE413RAA
■
High SRF and excellent Q values
■
Tight tolerances, many values at 1%
■
39 inductance values from 10 nH to 8.2 µH
Current Derating
120
110
100
Percent of rated
I
rms
This robust version of Coilcraft’s standard 1008CS series
features high temperature materials that pass NASA low
outgassing specifications and allow operation in ambient
temperatures up to 155°C. The leach-resistant base
metalization with tin-lead (Sn-Pb) terminations ensures
the best possible board adhesion.
90
80
70
60
50
25°C
Typical Q vs Frequency
120
100
100
90
80
100 nH
12 nH
40
30
20
10
0
47 nH
-40
-20
0
20
40
60
80
100
120
140 160
Ambient temperature (°C)
Q Factor
70
60
50
40
30
20
10
0
10
100
1000
10000
E
terminal
330 nH
750 nH
1800 nH
A
B
overall
F
G
F
C
I
J
I
D
Terminal wraparound:
approx 0.015/0,38 both ends
H
Frequency (MHz)
Suggested
Land Pattern
G
H
I
J
0.060 0.100 0.040 0.050
1,52 2,54 1,02 1,27
Typical L vs Frequency
1,000
900
800
750 nH
A max B max
0.115 0.110
2,92
2,79
C max D ref
0.080 0.020
2,03
0,51
E
F
0.080 0.020
2,03 0,51
All dimensions are without solder applied to the terminations. For
maximum dimensions with solder, add 0.006 inches / 0,152 mm.
Core material
Ceramic
Terminations
Tin-lead (63/37) over silver-platinum-glass frit
Ambient temperature
–55°C to +125°C with
Imax
current, +125°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +155 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000 per 7″ reel
Plastic tape: 8 mm wide, 0.3 mm thick, 4 mm pocket spacing,
2.0 mm pocket depth
Inductance (nH)
700
600
500
400
300
200
100
0
1
10
100
1000
100 nH
47 nH
12 nH
10000
330 nH
Frequency (MHz)
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document AE101-1 Revised 06/12/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft-cps.com
1008 CHIP INDUCTORS
AE413RAA Series (1008)
Part number
1
AE413RAA100_SZ
AE413RAA120_SZ
AE413RAA150_SZ
AE413RAA180_SZ
AE413RAA220_SZ
AE413RAA270_SZ
AE413RAA330_SZ
AE413RAA390_SZ
AE413RAA470_SZ
AE413RAA560_SZ
AE413RAA680_SZ
AE413RAA820_SZ
AE413RAA101_SZ
AE413RAA121_SZ
AE413RAA151_SZ
AE413RAA181_SZ
AE413RAA221_SZ
AE413RAA271_SZ
AE413RAA331_SZ
AE413RAA391_SZ
AE413RAA471_SZ
AE413RAA561_SZ
AE413RAA621_SZ
AE413RAA681_SZ
AE413RAA751_SZ
AE413RAA821_SZ
AE413RAA911_SZ
AE413RAA102_SZ
AE413RAA122_SZ
AE413RAA152_SZ
AE413RAA182_SZ
AE413RAA222_SZ
AE413RAA272_SZ
AE413RAA332_SZ
AE413RAA392_SZ
AE413RAA472_SZ
AE413RAA562_SZ
AE413RAA682_SZ
AE413RAA822_SZ
Inductance
2
(nH)
10 @ 50 MHz
12 @ 50 MHz
15 @ 50 MHz
18 @ 50 MHz
22 @ 50 MHz
27 @ 50 MHz
33 @ 50 MHz
39 @ 50 MHz
47 @ 50 MHz
56 @ 50 MHz
68 @ 50 MHz
82 @ 50 MHz
100 @ 25 MHz
120 @ 25 MHz
150 @ 25 MHz
180 @ 25 MHz
220 @ 25 MHz
270 @ 25 MHz
330 @ 25 MHz
390 @ 25 MHz
470 @ 25 MHz
560 @ 25 MHz
620 @ 25 MHz
680 @ 25 MHz
750 @ 25 MHz
820 @ 25 MHz
910 @ 25 MHz
1000 @ 25 MHz
1200 @ 7.9 MHz
1500 @ 7.9 MHz
1800 @ 7.9 MHz
2200 @ 7.9 MHz
2700 @ 7.9 MHz
3300 @ 7.9 MHz
3900 @ 7.9 MHz
4700 @ 7.9 MHz
5600 @ 7.9 MHz
6800 @ 7.9 MHz
8200 @ 7.9 MHz
Percent
tolerance
5,2
5,2
5,2
5,2
5,2,1
5,2
5,2
5,2
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5
5
5
Q
min
3
SRF min
4
(MHz)
4100
3300
2500
2500
2400
1600
1600
1500
1500
1300
1300
1000
1000
950
850
750
700
600
570
500
450
415
375
375
360
350
320
290
250
200
160
160
125
110
100
75
20
40
25
DCR max
5
(Ohms)
0.08
0.09
0.10
0.11
0.12
0.13
0.14
0.15
0.16
0.18
0.20
0.22
0.56
0.63
0.70
0.77
0.84
0.91
1.05
1.12
1.19
1.33
1.40
1.47
1.54
1.61
1.68
1.75
2.0
2.3
2.6
2.8
3.2
3.4
3.6
4.0
4.0
4.9
6.2
Imax
(mA)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
650
650
580
620
500
500
450
470
470
400
300
400
360
400
380
370
310
330
300
280
290
290
260
260
240
200
170
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 350 MHz
55 @ 350 MHz
55 @ 350 MHz
60 @ 350 MHz
60 @ 350 MHz
65 @ 350 MHz
65 @ 350 MHz
65 @ 350 MHz
60 @ 350 MHz
60 @ 350 MHz
60 @ 350 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
45 @ 100 MHz
35 @ 50 MHz
35 @ 50 MHz
35 @ 50 MHz
28 @ 50 MHz
28 @ 50 MHz
28 @ 50 MHz
22 @ 25 MHz
22 @ 25 MHz
20 @ 25 MHz
20 @ 25 MHz
16 @ 7.9 MHz
18 @ 7.9 MHz
18 @ 7.9 MHz
1. When ordering, please specify
tolerance
and
testing
codes:
AE413RAA822GSZ
Tolerance: F
= 1%
G
= 2%
J
= 5%
Testing:
Z
= Coilcraft Critical Products Environmental Stress Conditions Testing.
H
= Coilcraft Qual + Coilcraft Hi-Rel Burn-in
P
= Coilcraft Qual + MIL-STD-981 Class S Group A screening
N
= Coilcraft Qual + MIL-STD-981 Class B Group A screening
C
= Coilcraft Qual + MIL-STD-981 Class S Group A screening + MIL-STD-981 Class S Group B qualification
W
= Coilcraft Qual + MIL-STD-981 Class B Group A screening + MIL-STD-981 Class S Group B qualification
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/HP 4286A impedance analyzer with Coilcraft-provided correlation pieces.
3. Q measured using an Agilent/HP 4291A with an AgilentHP 16193 test fixture.
4. SRF measured using an Aglilent/HP 8753D network analyzer and a Coilcraft SMD-D test fixture.
5. DCR measured on a Cambridge Technology micro-ohmmeter and a Coilcraft CCF840 test fixture.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document AE101-2 Revised 06/12/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft-cps.com
