Double Balanced Mixer
Communications Band
Electrical Specifications :
(1)
Parameter
SSB Conversion
loss:
(2) (3)
Isolation
LO to RF:
LO to IF:
IF to RF:
Input 1 dB
Compression Point:
5.8-6.5
Model MC3xMS-3
Model MC3xMS-14
Specifications
Min
Typical
4.8 dB
38 dB
45 dB
32 dB
28 dB
+1 dBm
+4 dBm
+8 dBm
+12 dBm
+11
+14
+18
+22
dBm
dBm
dBm
dBm
MC33
MC34
MC36
MC37
MC33
MC34
MC36
MC37
MC33
MC34
MC36
MC37
Max
6.0 dB
LO Power
3 = +7 dBm
4 = +10 dBm
6 = +13 dBm
7 = +18 dBm
Model MC3xMS-3
Model MC3xMS-14
RF 5.8 to 6.5 GHz
Conditions
RF (GHz)
5.8-6.5
LO (GHz)
4.7-5.8
4.7-5.8
4.7-5.8
IF (MHz)
DC-2000
DC-2000
DC-2000
4.7-5.8
Input Third Order
Intercept Point:
5.8-6.5
4.7-5.8
DC-2000
LO Power:
(4)
5.8-6.5
4.7-5.8
DC-2000
+7 dBm
+10 dBm
+13 dBm
+18 dBm
Notes:
1. Specifications are guaranteed when tested as a downconverter in a 50 Ohm system at +25˚C with the nominal LO power. Specifications indicated as typical are not guaranteed.
2. Noise figure is typically within ±0.5 dB of conversion loss for IF frequencies greater than 10 MHz.
3. Conversion loss typically degrades less than 0.5 dB at +100˚C and improves less than 0.5 dB at -55˚C.
4. Usable LO drives are up to 2 dB below and 3 dB above nominal.
IF to RF Isolation – dB
5. See Application note M112, for aid in selecting the outline and for mounting and installation information.
10
MC3xMS-3
Outline: MS3C
Typical
Performance
at
25˚C
20
30
40
50
DC
MHz
2000
MC3xMS-14
Outline: MS3D
Conversion Loss (1.1 GHz IF) – dB
4
5
6
7
8
9
10
GHz
6.5
5.8
1.0
1.5
2.0
3.0
4.0
4.7
GHz
IF VSWR
5.8
LO VSWR
LO to RF, LO to IF Isolation – dB
10
20
30
40
50
4.7
LO-IF
LO-RF
GHz
RF VSWR
5.8
5.8
GHz
6.5
1.0
1.5
0
0.5
1.0
1.5
2.0
Relative Conversion Loss
vs. IF Freq. – dB
All dimensions are in inches and [mm].
2.0
3.0
4.0
DC
MHz
2000
DC
MHz
2000
