Low Voltage Differential Signaling Oscillators
67SMO
(+2.5V or +3.3V FIXED LVDS MODELS)
67SMO
STANDARD SPECIFICATIONS
Item
Generic part number
Frequency range
Frequency stability
(0˚C to
+70˚C)
over all conditions
Operating Conditions
Operating temperature
Input voltage (V
DD
)
Stand-by control voltage (Pin#1)
STANDARD SMD CLOCK OSCILLATORS
LVDS
Specifications
67SMO
※1
80.000 MHz to 300.000 MHz
67SMO(A) :
±100
ppm
67SMO(B) :
±50
ppm
67SMO(C) :
±30
ppm
67SMO(D) :
±25
ppm
0˚C to
+70˚C
+2.5V
DC
±5%
or
+3.3V
DC
±5%
V
IH
: 70%V
DD
min.
V
IL
: 30%V
DD
max.
※2
-0.5V to
+5.0V
DC
-50˚C to
+125˚C
70 mA max.
30μA max.
45% to 55% (at crossing point)
1 ns max. (20% to 80% of amplitude)
V
OL
:
+1.10V,
Typical
V
OH
:
+1.43V,
Typical
100Ω (OUT-OUTN)
0.33V, Typical
1.25V, Typical
200 ns max.
10 ms max.
10 ms max.
1 ps max.
±5
ppm max. at
+25˚C ±3˚C
for first year
+250˚C ±10˚C
for 10 seconds
+170˚C ±10˚C
for 1 to 2 minutes (preheating)
67SMO
7.0±0.2
#6
#5
#4
5.0±0.2
#1
#2
#3
1.14 1.14
0.26
1.4
1.4
1.4
#1
#6
#2
#5
2.54 2.54
5.08
PIN
1
2
3
4
5
6
CONNECTION
"L"
OPEN or "H"
N.C.
GND
Z
OUTPUT
Z
C-OUTPUT
V
DD
Z : high impedance
#3
#4
1.2 2.6 1.2
OUTPUT WAVEFORM
t
TR
T
V
PP
VOS
VOL
GND
TF
VOH
80% V
PP
50% V
PP
20% V
PP
Absolute Max. Ratings
Supply voltage
Storage temperature
Input current (Pin#1 = Open or V
IH
)
Stand-by current (Pin#1=V
IL
)
Output (0˚C to
+70˚C)
Symmetry
Rise and fall times
"0" level
"1" level
Load
Differential output voltage
Offset voltage
Disable delay time
Enable delay time
Startup time
RMS jitter (12 kHz to 20 MHz band)
Aging
Reflow condition
1.7max.
(※1) Final exact part number to be determined with frequency, frequency stability and input voltage.
e.g. 67SMO(3.3VC) 164.355 MHz.
(※2) Internal crystal oscillation to be halted (Pin #1=V
IL
).
Symmetry=t/T×100(%)
PACKAGE DATA
TEST CIRCUIT
T.P.
A
#6
V
DD
0.1μF
TRI-
STATE
Item
Package
67SMO
Metal
Ceramic
Seam
Tungsten (metalized)
Gold / Nickel
(surface) / (under)
Compliant (Pb-free)
Lid
Base
Sealing
Terminal
Terminal plating
RoHS
#4
#5
OUT
PUT
GND
100Ω
T.P.
V
DD
OUTPUT
#2
#1
N.C.
#3
E/D
SW
TAPE SPECIFICATIONS
4.0±0.1
0.1
φ
1.5
+-
0
1.75±0.1
L
2.0±0.1
SOLDERING PATTERN
1.6 0.94 1.6 0.94 1.6
1.6
D
A
J
2.2
1.6
0.01μF
∼
0.1μF
M
B
F
A
2.54
5.08
2.54
B
C
D
F
J
L
M Reel Dia. Qty/Reel
245
1000pcs
7.5 5.5 16.0 7.5 8.0 2.0 0.3 2.2
C
91
CLK OSC
Actual Size
