T-1 (3mm) CYLINDRICAL LED LAMPS
L-1334IT HIGH EFFICIENCY RED
L-1334EC HIGH EFFICIENCY RED
L-1334SRx SUPER BRIGHT RED
L-1334SGx SUPER BRIGHT GREEN
L-1334Gx GREEN
L-1334Nx PURE ORANGE
L-1334PGx PURE GREEN
L-1334Yx YELLOW
Features
!
WIDE
!
LOW
Description
The High Efficiency Red source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide Orange Light
Emitting Diode.
The Green and Super Bright Green source color devices are
made with Gallium Phosphide Green Light Emitting Diode.
The Yellow source color devices are made with Gallium Arsenide
Phosphide on Gallium Phosphide Yellow Light Emitting Diode.
The Super Bright Red source color devices are made with
Gallium Aluminum Arsenide Red Light Emitting Diode.
The Pure Green source color devices are made with Gallium
Phosphide Pure Green Light Emitting Diode.
The Pure Orange source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Pure Orange Light
Emitting Diode.
VIEWING ANGLE.
AND RUGGED.
POWER CONSUMPTION.
LIFE-SOLID STATE RELIABILITY.
!
RELIABLE
!
LONG
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: KDA0065
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: SEP/30/2001
DRAWN: X.M.Zhou
PAGE: 1 OF 7
Selection Guide
Par t No .
L-1334IT
L-1334EC
L-1334GT
L-1334GC
L-1334YT
L-1334YC
L-1334SGT
L-1334SGC
L-1334SRC
L-1334SRT
L-1334SRWT
L-1334NT
L-1334NC
L-1334PGT
L-1334PGC
PURE ORANGE (GaAsP/GaP)
PURE ORANGE (GaAsP/GaP)
PURE GREEN (GaP)
PURE GREEN (GaP)
SUPER BRIGHT RED (GaAlAs)
Dic e
HIGH EFFICIENCY RED (GaAsP/GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
GREEN (GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
YELLOW (GaAsP/GaP)
SUPER BRIGHT GREEN (GaP)
SUPER BRIGHT GREEN (GaP)
L en s Ty p e
RED TRANS.
WATER CLEAR
GREEN TRANS.
WATER CLEAR
YELLOW TRANS.
WATER CLEAR
GREEN TRANS.
WATER CLEAR
WATER CLEAR
RED TRANSPARENT
WHITE DIFFUSED
ORANGE TRANS.
WATER CLEAR
GREEN TRANS.
WATER CLEAR
Iv (m c d )
@ 10 m A *20 m A
Min .
3
3
2
2
1
1
*5
*5
*20
*20
*20
3
3
0.7
0.7
Ty p .
5
5
6
6
3
3
*10
*10
*60
*60
*50
8
8
1.5
1.5
V i ew i n g
An g l e
2θ1/2
13 0 °
130°
13 0 °
13 0 °
13 0 °
13 0 °
130°
13 0 °
130°
13 0 °
13 0 °
13 0 °
130°
13 0 °
130°
Notes:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. * Luminous intensity with asterisk is measured at 20mA.
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
Hig h
E f f i c i en c y
R ed
10 5
30
160
5
Gr een
105
25
140
5
Yello w
10 5
30
14 0
5
S u p er
B r ig h t
R ed
10 0
30
15 5
5
S u p er
B r ig h t
Gr een
105
25
140
5
Pu r e
Or an g e
105
30
145
5
Pu r e
Gr een
105
25
13 5
5
Un it s
mW
mA
mA
V
-40
°
C To +85
°C
260
°
C For 5 Seconds
SPEC NO: KDA0065
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: SEP/30/2001
DRAWN: X.M.Zhou
PAGE: 2 OF 7
