DG181AA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> DG181AA

DG181AA: DescriptionSPST, 2 Func, 1 Channel, MBCY10, PACKAGE-10; CategoryAnalog mixed-signal IC The signal circuit; File Size1MB，10 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

DG181AA Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DG181AA	-	-	View	Buy Now

DG181AA Overview

SPST, 2 Func, 1 Channel, MBCY10, PACKAGE-10

DG181AA Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	BCY
package instruction	,
Contacts	10
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SPST
JESD-30 code	O-MBCY-W10
JESD-609 code	e0
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	1
Number of functions	2
Number of terminals	10
Nominal off-state isolation	50 dB
Maximum on-state resistance (Ron)	30 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	METAL
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	130 ns
Maximum connection time	150 ns
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	WIRE
Terminal location	BOTTOM
