LSI53C875JBE datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> LSI53C875JBE

LSI53C875JBE: DescriptionSCSI Bus Controller, CMOS, PBGA169, 23 X 23 MM, 1.50 MM PITCH, PLASTIC, MO-151, BGA-169; CategoryThe embedded processor and controller Microcontrollers and processors; File Size365KB，4 Pages; ManufacturerLSC/CSI; Websitehttps://lsicsi.com

Download Datasheet Parametric Compare View All

LSI53C875JBE Overview

SCSI Bus Controller, CMOS, PBGA169, 23 X 23 MM, 1.50 MM PITCH, PLASTIC, MO-151, BGA-169

LSI53C875JBE Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	LSC/CSI
Parts packaging code	BGA
package instruction	BGA,
Contacts	169
Reach Compliance Code	compliant
ECCN code	3A001.A.3
Address bus width	32
Bus compatibility	PCI
maximum clock frequency	80 MHz
Maximum data transfer rate	40 MBps
External data bus width	32
JESD-30 code	S-PBGA-B169
JESD-609 code	e0
length	23 mm
Number of terminals	169
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	BGA
Package shape	SQUARE
Package form	GRID ARRAY
Peak Reflow Temperature (Celsius)	225
Certification status	Not Qualified
Maximum seat height	2.4 mm
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	BALL
Terminal pitch	1.5 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	30
width	23 mm
uPs/uCs/peripheral integrated circuit type	BUS CONTROLLER, SCSI

LSI53C875JBE Preview

LSI53C875E

SCSI CONTROLLER

The Communications Company

™

P C I - U LT R A S C S I C O N T R O L L E R

BENEFITS

• Pin-for-pin replacement for

LSI53C825 and LSI53C825AE

devices

• Minimal software and hardware

modifications required for Ultra

SCSI support

• Compact 160-pin PQFP reduces

board space requirements

(LSI53C875E, LSI53C875JE)

OVERVIEW

The LSI53C875E controller supports Ultra SCSI transfers, enabling the

chip to transfer SCSI data at up to 40 MBps across a 16-bit bus. Ultra SCSI

is an extension of the SCSI-3 standard that expands the bandwidth of the

SCSI bus and allows faster synchronous SCSI transfer rates-approximately

double the synchronous transfer rates of fast SCSI-2. The LSI53C875E provides

full SCSI-2 capabilities and reduces the requirements for system BIOS support

with a local memory interface. It also features LSI Logic TolerANT SCSI driver

and receiver technology, for reliable operation in all cabling environments. It

is designed to connect gluelessly to the Peripheral Component Interconnect

(PCI) bus, and supports PCI extended access cycles, enabling the system

architect to take advantage of PCI’s performance potential.

• Alternative 169 BGA package

(LSI53C875JBE)

• Direct PCI to SCSI connection

• Fully supported by SDMS

software for complete PC-based

operating system support

FEATURES

• Performs wide high-speed SCSI

bus transfers in single-ended

and differential mode up to:

• 40 MBps synchronous (Ultra)

• 14 MBps asynchronous

• SCRIPTS

™

Instruction Prefetch

• 536-byte buffer allows burst

length of up to 128 transfers

• Load and store instruction

• 4 KB static RAM for SCRIPTS

instruction storage

• 32 additional scratchpad

registers for user-defined functions

The LSI53C875E and SDMS

™

software provide a total Ultra SCSI solution

in PC and workstation environments. LSI Logic’s SDMS software package

supports the entire LSI53C8XX family of PCI-to-SCSI controllers plus a wide

range of SCSI peripheral devices.

Included in the performance-enhancing features on the LSI53C875E is

a 4 KB static RAM for SCRIPTS (the LSI Logic developed SCSI programming

language) instruction storage, which allows tailored SCSI sequences to be

executed locally. A 536-byte DMA FIFO increases system performance by

allowing burst lengths of up to 128 transfers. Other features include:

• SCRIPTS instruction prefetch which permits fetching four or eight double

words of instructions or instruction operands.

• Support for PCI extended access cycles: Memory Read Multiple, Memory

Read Line, and Memory Write and Invalidate.

LSI53C875E SCSI Controller

• Selectable IRQ disable, allowing system designers to customize their

system interface.

• SCSI Selected as ID register, improving SCRIPTS coding and system tracking.

• Load and Store instruction allows the programmer an efficient instruction

option to load data directly to/from memory and from/to an internal register,

reducing the number of l/O instructions to implement a SCRIPTS task.

FLEXIBILITY FEATURES

• Supports single-ended and differential modes

• Selectable IRQ disable

• SCSI Selected as ID register

• Support for both 3.3 volt and 5 volt PCI interfaces

• High-level programming interface (SCSI SCRIPTS)

• Allows tailored SCSI sequences to be executed from main memory

• Accommodates changes in the logical I/O interface definition

• Low-level access to all registers and all SCSI bus signals

COMPATIBILITY FEATURES

• Compiler-compatible with existing LSI53C7XX and LSI53C8XX SCRIPTS

• Full complement of LSI Logic SCSI SCRIPTS development tools available

• BIOS and driver support for hard disk, tape, CD-ROM, and removable

media peripherals for all of the major operating systems, including:

• Windows NT 4.0

• Windows 95/98

• DOS

• Linux

• NetWare

• SCO UnixWare

™

• OS/2 Warp

• Solaris

RELATED LSI53C875E PRODUCTS

•

LSI53C875JE — the LSI53C875E with JTAG availability and a

160-pin PQFP package

LSI53C875JBE — the LSI53C875E with a 169 BGA package

LSI8751SPE host adapter

LSI8751D host adapter

•

SCSI Connection

SCSI Term Connection

Vdd

Vss

SCSI Bus

PCI Bus

LSI53C875E

SCLK

Peripheral

40 MHz

Oscillator

CPU Baseboard

CPU Box

Figure 1: LSI53C875E system diagram

LSI53C875E SCSI Controller

For more information please visit

the

LSI Logic web site at:

http://storageio.lsilogic.com

LSI Logic Corporation

North American Headquarters

Milpitas, CA

Tel: 800 574 4286

LSI Logic Europe Ltd.

European Headquarters

United Kingdom

Tel: 44 1344 426544

Fax: 44 1344 481039

LSI Logic KK Headquarters

Tokyo, Japan

Tel: 81 3 5463 7165

Fax 81 3 5463 7820

ISO 9000 Certified

LSI Logic logo design and TolerANT are registered

trademarks, and SCRIPTS and SDMS are trade-

marks of LSI Logic Corporation. All other brand

and product names may be trademarks of their

respective companies.

LSI Logic Corporation reserves the right to make

changes to any products and services herein at

any time without notice. LSI Logic does not

assume any responsibility or liability arising out of

the application or use of any product or service

described herein, except as expressly agreed to

in writing by LSI Logic; nor does the purchase,

lease, or use of a product or service from

LSI Logic convey a license under any patent

rights, copyrights, trademark rights, or any other

of the intellectual property rights of LSI Logic or

of third parties.

Order No. S20027

2/01-500 – Printed in USA
