Agilent HSMx-A16x-xxxxx PLCC-2
Surface Mount LED Indicator
Black Surface Tinted
Data Sheet
Features
• Industry standard PLCC-2 package
• High reliability LED package
Description
This family of SMT LEDs is packaged in
the industry standard PLCC-2 package.
These SMT LEDs have high reliability
performance and are designed to work
under a wide range of environmental
conditions. This high reliability feature
makes them ideally suited to be used
under harsh interior signs application
conditions. This SMT LED package
come with a black surface and tinted
which is specially designed for signs
application to minimize ambient
reflection to improve contrast.
To facilitate easy pick & place
assembly, the LEDs are packed in EIA-
compliant tape and reel. Every reel will
be shipped in single intensity and color
bin, except red color, to provide close
uniformity.
These LEDs are compatible with IR
solder reflow process. Due to the high
reliability feature of these products,
they can also be mounted using
through-the-wave soldering process.
The super wide viewing angle at 120°
makes these LEDs ideally suited for
panel, push button, or general
backlighting in automotive interior,
office equipment, industrial equipment,
and home appliances. The flat top
emitting surface makes it easy for
these LEDs to mate with light pipes.
With the built-in reflector pushing up
the intensity of the light output, these
LEDs are also suitable to be used as
LED pixels in interior electronic signs.
• High brightness using AlInGaP and
InGaN dice technologies
• Available in full selection of colors
•
Super wide viewing angle at 120°
• Available in 8 mm carrier tape on 7
inch reel (2000 pieces)
• Compatible with both IR and TTW
soldering process
• Black Surface Tinted
Applications
• Electronic signs and signals
• Interior full color sign
• Variable message sign
CAUTION:
HSMM and HSMN-A1xx-xxxxx LEDs are Class 2 ESD sensitive. Please observe appropriate precautions
during handling and processing. Refer to Agilent Application Note AN-1142 for additional details.
Absolute Maximum Ratings (T
A
= 25°C)
Parameters
DC Forward Current
[1]
Peak Forward Current
[2]
Power Dissipation
Reverse Voltage
Junction Temperature
Operating Temperature
Storage Temperature
Notes:
1. Derate linearly as shown in figure
2. Duty factor = 10%, Frequency = 1kHz.
3. Drive Current between 10mA and 30mA are recommended for best long term performance
4. Operation at current below 5mA is not recommended.
HSMC/A
30 mA
[3,4]
100mA
63mW
5
110°C
-55°C to +100°C
-55°C to +100°C
HSMV/Z
30 mA
[3,4]
100mA
72mW
5
110°C
-55°C to +100°C
-55°C to +100°C
HSMM/N
30 mA
100mA
114mW
5
110°C
-55°C to +100°C
-55°C to +100°C
Optical Characteristic (T
A
= 25°C)
Peak
Dice
Wavelength
Technology
λ
PEAK
(nm)
Typ.
AlInGaP
AlInGaP
AlInGaP
AlInGaP
InGaN
InGaN
592
594
635
639
523
468
Dominant
Wavelength
λ
D (nm)[1]
Typ.
590
592
626
630
525
470
Viewing Angle
2θ
1/2 [2]
(Degrees)
Typ.
120
120
120
120
120
120
Luminous
Luminous
Intensity/
Efficacyη
v[3]
Total Flux
(lm/W)
I
v
(mcd)/F
v
(mlm)
Typ
Typ.
480
500
150
155
500
75
0.45
0.45
0.45
0.45
0.45
0.45
Color
Part Number
Amber
Amber
Red
Red
Green
Blue
Notes:
HSMA-A16x
HSMU-A160
HSMC-A16x
HSMZ-A160
HSMM-A16x
HSMN-A16x
1. The dominant wavelength,
λ
D
, is derived from the CIE Chromaticity Diagram and represents the color of the device.
2. θ
1/2
is the off-axis angle where the luminous intensity is 1/2 the peak intensity.
3. Radiant intensity, I
e
in watts/steradian, may be calculated from the equation I
e
= I
v
/η
v
, where I
v
is the luminous intensity in candelas and
η
v
is the
luminous efficacy in lumens/watt.
Electrical Characteristic (T
A
= 25°C)
Forward Voltage
V
F
(Volts) @ I
F
= 20mA
Typ
HSMC/A
HSMV/Z
HSMM/N
1.9
2.2
3.4
Max
2.4
2.6
4.05
Reverse Voltage
V
R
@ 100µA
Min
5
5
-
Reverse Voltage
V
R
@ 10µA
Min
-
-
5
Thermal Resistance
Rθ
JP
(°C/W)
Typ
280
280
280
3
Dice Technology
