AD7549KN: DescriptionPARALLEL, 4 BITS INPUT LOADING, 0.8us SETTLING TIME, 12-BIT DAC, PDIP20, 0.300 INCH, SKINNY, PLASTIC, DIP-20; CategoryAnalog mixed-signal IC converter; File Size1MB，9 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

AD7549KN Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AD7549KN	-	-	View	Buy Now

AD7549KN Overview

PARALLEL, 4 BITS INPUT LOADING, 0.8us SETTLING TIME, 12-BIT DAC, PDIP20, 0.300 INCH, SKINNY, PLASTIC, DIP-20

AD7549KN Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	0.300 INCH, SKINNY, PLASTIC, DIP-20
Contacts	20
Reach Compliance Code	unknown
Converter type	D/A CONVERTER
Enter bit code	BINARY, OFFSET BINARY
Input format	PARALLEL, 4 BITS
JESD-30 code	R-PDIP-T20
JESD-609 code	e0
length	25.2 mm
Maximum linear error (EL)	0.0122%
Humidity sensitivity level	NOT APPLICABLE
Number of digits	12
Number of functions	1
Number of terminals	20
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
Certification status	COMMERCIAL
Maximum seat height	5.33 mm
Nominal settling time (tstl)	0.8 µs
Nominal supply voltage	15 V
surface mount	NO
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE
width	7.62 mm
