SMD Film Capacitors
LDB
series - PPS dielectric RoHS 6
Standard version
Rated
capacitance
3300 pF
3900 pF
4700 pF
5600 pF
6800 pF
8200 pF
0.010 µF
0.012 µF
0.015 µF
0.018 µF
0.022 µF
0.027 µF
0.033 µF
0.039 µF
0.047 µF
0.056 µF
0.068 µF
0.082 µF
0.10 µF
12.06
12.06
12.06
12.06
12.06
12.06
12.06
12.06
12.10
12.10
12.10
12.10
3000
3000
3000
3000
3000
3000
3000
3000
2250
2250
2250
2250
1.1
1.1
1.1
1.1
1.1
1.1
1.2
1.3
1.7
1.7
1.7
2.0
LDBAA2120 - C5 - -
LDBAA2150 - C5 - -
LDBAA2180 - C5 - -
LDBAA2220 - C5 - -
LDBAA2270 - C5 - -
LDBAA2330 - C5 - -
LDBAA2390 - C5 - -
LDBAA2470 - C5 - -
LDBAB2560 - C5 - -
LDBAB2680 - C5 - -
LDBAB2820 - C5 - -
LDBAB3100 - C5 - -
L
e
Fre
ead
16 V
DC
Size code
Pcs per
reel
Hmax
[mm]
Part number
Size code
12.06
12.06
12.06
12.06
12.06
12.06
12.06
12.06
12.10
12.10
12.10
12.10
12.10
12.10
12.10
18.12
18.12
18.12
18.12
Pcs per
reel
3000
3000
3000
3000
3000
3000
3000
3000
2250
2250
2250
2250
2250
2250
2250
4000
4000
4000
3000
50 V
DC
Hmax
[mm]
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.1
1.4
1.5
1.5
1.5
1.7
1.9
2.3
1.7
1.7
1.7
2.0
Part number
LDBCA1330 - C5 - -
LDBCA1390 - C5 - -
LDBCA1470 - C5 - -
LDBCA1560 - C5 - -
LDBCA1680 - C5 - -
LDBCA1820 - C5 - -
LDBCA2100 - C5 - -
LDBCA2120 - C5 - -
LDBCB2150 - C5 - -
LDBCB2180 - C5 - -
LDBCB2220 - C5 - -
LDBCB2270 - C5 - -
LDBCB2330 - C5 - -
LDBCB2390 - C5 - -
LDBCB2470 - C5 - -
LDBCC2560 - C5 - -
LDBCC2680 - C5 - -
LDBCC2820 - C5 - -
LDBCC3100 - C5 - -
Rated
capacitance
3300 pF
3900 pF
4700 pF
5600 pF
6800 pF
8200 pF
0.010 µF
0.012 µF
0.015 µF
0.018 µF
0.022 µF
0.027 µF
0.033 µF
0.039 µF
0.047 µF
0.056 µF
0.068 µF
0.082 µF
0.10 µF
Tolerance - G = ±2%; J = ±5%;
Packaging - N = Taped; A to Z = Special;
Internal use
±2% Tolerance
available
Size code
L (mm)
W (mm)
P/N 5
th
digit
12.06
3.3 +0.3
- 0.1
1.7 ± 0.2
A
12.10
3.3 +0.3
- 0.1
2.5 ± 0.3
B
18.12
4.7 +0.3
- 0.2
3.3 ± 0.3
C
07/2008
12
SMD Film Capacitors
LDB
series - PPS dielectric RoHS 6 - technical data
Plates
Winding
Terminations
Marking
Climatic category
Aluminium layer deposited by evaporation under vacuum.
Non inductive - Stacked technology.
Four layers: aluminium, brass, nickel, pure tin.
On packaging only.
55 / 125 / 56
Electrical data
Operating temperature range
Rated voltage (V
R
)
Category voltage (V
C
)
Size range
Capacitance range
Capacitance values
Capacitance tolerances
Dissipation factor (tgδ)
Dielectric absorption
-55 to + 125 °C
16 - 50 V
DC
V
C
= V
R
up to 105 °C.
For temperatures between 105 and 125 °C a decreasing factor of
1.25 % per degree °C has to be applied on the D.C. rated voltage
12.06 to 18.12
3300 pF to 0.1 μF
E12 series
± 2 % (G); ± 5 % (J)
≤ 0.6 % (T = 25 ± 5 °C; f = 1 kHz)
0.02%
≥ 3 GΩ
Test conditions:
T = 25 ± 5 °C; charging time: 1 min.
Charging voltage:
10 V
DC
for V
R
= 16 V
DC
50 V
DC
for V
R
= 50 V
DC
1.75 x V
R
(5 s; T = 25 ± 5 °C)
Insulation resistance
Surge voltage test
Tests and performances
Damp heat
(40 °C / 93% R.H.; 56 days)
Endurance
(125 °C; 2000 h; 1.25 x V
C
)
Rapid change of temperature
(1h at -55 °C;1h at +125 °C; 1000 cycles)
Reflow (as per reflow recommendations, see
page 14)
Bending
(1 to 6 mm deflection)
Long term stability
(2 years)
Reliability
(REF. MIL HDBK 217)
│∆C/C│≤ 5%;│∆tgδ│≤ 30 x 10
-4
;IR ≥ 50% of the limit value
│∆C/C│≤ 3%;│∆tgδ│≤ 30 x 10
-4
;IR ≥ 50% of the limit value
│∆C/C│≤ 3%
│∆tgδ│≤ 50 x 10
-4
IR ≥ limit value
No mechanical damage
│∆C/C│≤ 3% ;│∆tgδ│≤ 50 x 10
-4
; IR ≥ limit value
No mechanical damage
│∆C/C│≤ 1%
No visible damage on the terminations (pealing) neither on the body
(cracking)
│∆C/C│≤ 1%
Failure rate ≤ 1 Fit
1 Fit = 10
-9
failures / (components * hours)
13
07/2008
