MOS INTEGRATED CIRCUIT
µ
PD78C10A, 78C11A, 78C12A
8-BIT SINGLE-CHIP MICROCOMPUTER (WITH A/D CONVERTER)
DESCRIPTION
The
µ
PD78C11A is a CMOS 8-bit microprocessor which can integrate 16-bit ALU, ROM, RAM, an A/D converter,
a multi-function timer/event counter, and a general-purpose serial interface into a single chip, then expand the
memory (ROM/RAM) up to 60K bytes externally. The
µ
PD78C10A is a ROM-less product of the
µ
PD78C11A, and can
directly address the external memory up to 64k bytes. The
µ
PD78C12A is a product which has more built-in ROM
capacity than the
µ
PD78C11A, and its memory (ROM/RAM) can be externally extended up to 56K bytes. The
µ
PD78C10A,
µ
PD78C11A, and
µ
PD78C12A operated at low power consumption, because they have a CMOS
construction. Also, they can hold data with low power consumption by using standby function.
On-chip PROM products,
µ
PD78CP14 and
µ
PD78CP18 which are ideal for evaluation or preproduction use during
system development, early start-up and short-run multiple-device production of application sets, are available.
FEATURES
•
Abundant 159 types of instructions : 87AD series instruction set, multiplication/division instructions,
16-bit operation instructions
•
Instruction cycle : 0.8
µ
s (at 15 MHz operation)
•
On-chip ROM : 4096W
×
8 (
µ
PD78C11A), 8192W
×
8 (
µ
PD78C12A)
Non (
µ
PD78C10A)
•
On-chip RAM : 256W
×
8
•
High-precision 8-bit A/D converter : 8 analog inputs
•
General-purpose serial interface : Asynchronous, synchronous, I/O interface mode
•
Multi-function 16-bit timer/event counter
•
Two 8-bit timers
•
I/O lines : 32 (
µ
PD78C10A), 44 (
µ
PD78C11A, 78C12A)
•
Interrupt function (external - 3, internal - 8) : Non-maskable interrupt
×
1, maskable interrupt
×
10
•
Standby function : HALT mode, hardware/software STOP mode
•
Zero-cross detection function : (2 inputs)
•
On-chip pull-up resistor (port A, B, C:
µ
PD78C11A, 78C12A only) by mask option
Caution
The
µ
PD78C10A does not hava a mask option.
The information in this document is subject to change without notice.
Document No. IC-2678C
(O. D. No. IC-7769E)
Date Published February 1995 P
Printed in Japan
The mark
5
shows major revised points.
©
