SMP18FSZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> SMP18FSZ

SMP18FSZ: Description8 CHANNEL, SAMPLE AND HOLD AMPLIFIER, 3.5 us ACQUISITION TIME, PDSO16, SOIC-16; CategoryAnalog mixed-signal IC Amplifier circuit; File Size993KB，9 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

SMP18FSZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SMP18FSZ	-	-	View	Buy Now

SMP18FSZ Overview

8 CHANNEL, SAMPLE AND HOLD AMPLIFIER, 3.5 us ACQUISITION TIME, PDSO16, SOIC-16

SMP18FSZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	SOP,
Contacts	16
Reach Compliance Code	unknown
Nominal acquisition time	3.5 µs
Amplifier type	SAMPLE AND HOLD CIRCUIT
Maximum analog input voltage	3 V
Minimum analog input voltage	-3 V
maximum rate of descent	0.04 V/s
JESD-30 code	R-PDSO-G16
JESD-609 code	e3
length	9.9 mm
Humidity sensitivity level	1
Negative supply voltage upper limit	-8.5 V
Nominal Negative Supply Voltage (Vsup)	-5 V
Number of functions	8
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Certification status	COMMERCIAL
Sample and hold/Track and hold	SAMPLE
Maximum seat height	1.75 mm
Supply voltage upper limit	8.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
width	3.9 mm
