ALUMINUM ELECTROLYTIC CAPACITOR
GLR
立式
85°C
½漏電流型品
Low leakage current 85°C Series
i
2,000
85
i
i
Low leakage current for timing or high reliability products required
i
Life guaranteed 2,000 hours/85°C.
i
Specifications
Item
Operating Temperature
range
Rated Voltage
Capacitance Range
容量範圍
Capacitance Tolerance
Leakage Current
Dissipation Factor
(120Hz, 20°C)
Temperature
Characteristics
(120Hz)
Load Life
Performance Characteristics
-40 + 85°C
6.3V
∼
100V
0.1
∼
10,000
µF
±20%
(120Hz, 20°C)
I
≤
0.002CV or 0.4
µA,
whichever is greater after 2 minutes application of rated voltage.
Rated voltage (V)
6.3
10
16
25
35
50
63
100
Tan
δ
(max.)
0.21
0.17
0.14
0.12
0.12
0.10
0.08
0.08
For capacitance of more than 1,000µF, add 0.02 for every increase of 1,000µF
Impedance Ratio / Stability at Low Temperature
Rated voltage (V)
6.3
10
16
25
35
50
63
100
Z (-25°C) / Z (20°C)
3
2
2
1.5
1.5
1.5
1.5
1.5
Z (-40°C) / Z (20°C)
5
4
3
2
2
2
2
2
After 2,000 hours application of WV at 85°C, capacitor shall meet the characteristics requirements mentioned below.
Capacitance change
Within
±15%
of initial value
Tan
δ
150% or less of initial specified value
Leakage current
Initial specified value or less
After leaving capacitors under no load at 85°C for 1,000 hours and applying voltage according to JIS C5102 and C5141,
they shall meet the specified value as load life characteristics listed above.
Shelf Life
i
Dimension
D
φ
P
5
2.0
6.3
2.5
1.0
0.5
8
3.5
10
5.0
0.6
1.5
13
5.0
16
7.5
18
7.5
φ
d
α
0.8
i
Standard Products Table
WV(SV)
Cap(µF)
0.1∼0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
2200
3300
4700
6800
10000
6.3
(10)
10
(13)
16
(20)
25
(32)
35
(44)
10 x 12
10 x 20
13 x 25
16 x 25
16 x 32
18 x 36
18 x 40
5 x 11
5 x 11
5 x 11
5 x 11
110 6.3 x 11
6.3 x 11 180
8 x 11
8 x 11
310 10 x 12
10 x 12 400 10 x 16
390 10 x 16 530 10 x 20
650 13 x 20 810 13 x 25
1060 16 x 25 1200 16 x 25
1270 16 x 32 1420 16 x 36
1500 16 x 36 1650 18 x 36
1760 18 x 36 1890
1900
5 x 11
45
55
5 x 11
70
85
5 x 11
100 6.3 x 11
100 6.3 x 11 140 6.3 x 11
140 6.3 x 11 170
8 x 11
230
8 x 11
280 10 x 12
370 10 x 16 400 10 x 20
420 10 x 20 490 13 x 20
550 13 x 20 660 13 x 25
910 16 x 25 1010 16 x 25
1300 16 x 36 1440 18 x 36
1550 18 x 40 1720
1820
50
(63)
5 x 11
5 x 11
5 x 11
5 x 11
5 x 11
5 x 11
110 6.3 x 11
140
8 x 11
190
8 x 11
300 10 x 16
440 13 x 20
550 13 x 20
680 16 x 25
1100 16 x 32
1580
63
(75)
10
23
40
45
70
6.3 x 11
110
8 x 11
165
8 x 11
190 10 x 12
320 10 x 20
490 13 x 20
600 13 x 25
760 16 x 25
1140 18 x 36
75
115
170
200
330
550
710
850
1330
D
φ
x L (mm)
100
(125)
5 x 11
5 x 11
19
5 x 11
28
5 x 11
45
5 x 11
50
8 x 11
90
10 x 12 136
10 x 16 180
10 x 20 220
13 x 20 370
16 x 25 580
16 x 32 730
18 x 36
910
Case Size ripple
Ripple (mA) at 85°C 120Hz
Embedded System
