SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
Alchip
TM
-
●
φ4
Downsized, 85℃
through
φ18
case sizes are fully lined up
MVA
●
Endurance : 2,000 hours at 85℃
●
Suitable to fit for downsized equipment
●
Solvent resistant type except 100 to 450V
dc
(see PRECAUTIONS AND GUIDELINES)
●
RoHS Compliant
MVA
Series
105℃
MVE
◆SPECIFICATIONS
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
-40 to +85
℃
4 to 450V
dc
(at 20
℃
, 120Hz)
±20%
(M)
Rated voltage (V
dc
)
4 to 100V
160 to 450V
D55 to JA0 I=0.01CV or 3μA, whichever is greater.(after 2 minutes)
-
KE0 to MN0 I=0.03CV or 4μA, whichever is greater.(after 1 minute)
I=0.04CV+100μA max.(after 1 minute)
Where, I : Max. leakage current (μA), C : Nominal capacitance (μF), V : Rated voltage (V)
(at 20
℃
)
Rated voltage (V
dc
)
4V 6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 400 & 450V
D55 to JA0 0.42 0.35 0.30 0.26 0.16 0.14 0.12 0.12 0.12
-
-
tan (Max.)
δ
KE0 to MN0 -
0.38 0.34 0.30 0.26 0.22 0.18 0.14 0.10
0.20
0.25
When nominal capacitance exceeds 1,000μF, add 0.02 to the value above for each 1,000μF increase.
(at 20
℃
, 120Hz)
Rated voltage (V
dc
)
4V 6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 400 & 450V
Z(-25
℃
)/Z(+20
℃
)
3
2
2
2
2
2
3
4
7
-
-
D55 to JA0
Z(-40
℃
)/Z(+20
℃
) 17
4
3
3
3
4
6
8
10
-
-
Z(-25
℃
)/Z(+20
℃
) -
2
2
2
2
2
3
4
5
3
6
KE0 to MN0
Z(-40
℃
)/Z(+20
℃
) -
(at 120Hz)
3
3
3
4
5
8
10
12
6
10
The following specifications shall be satisfied when the capacitors are restored to 20
℃
after the rated voltage is applied for 2,000 hours
at 85
℃
.
Size code
D55 to JA0
D55 to JA0
KE0 to MN0
Rated voltage (V
dc
)
4V & 6.3V
10 to 100V
6.3 to 450V
Capacitance change
≦
±30%
of the initial value
≦
±20%
of the initial value
D.F. (tan )
δ
≦200%
of the initial specified value
≦200%
of the initial specified value
Leakage current
≦The
initial specified value
≦The
initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20
℃
after exposing them for 1,000 hours at 85
℃
without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Size code
D55 to JA0
D55 to JA0
KE0 to MN0
Rated voltage
4V & 6.3V
10 to 100V
6.3 to 450V
Capacitance change
≦
±30%
of the initial value
≦
±20%
of the initial value
D.F. (tan )
δ
≦200%
of the initial specified value
≦200%
of the initial specified value
Leakage current
≦The
initial specified value
≦The
initial specified value
Characteristics
Dissipation Factor
(tanδ)
Low Temperature
Characteristics
(Max. Impedance Ratio)
Endurance
Shelf Life
◆DIMENSIONS
[mm]
●
Terminal Code :
●
Size code : D55
A
to MN0
W
●
Terminal
●
Size
Code : G
code : LH0 to MN0
0.3max.
W
0.3max.
L
±
0.3(Note)
A
±
0.2
L
±
0.5
A
±
0.2
Note : L±0.5 for HA0 to MN0
: Dummy terminals
C
B
A
L
Size code D
5.2 4.3 4.3 5.1
4
D55
5.2 5.3 5.3 5.9
5
E55
6.3 5.2 6.6 6.6 7.2
F55
6.3 7.7 6.6 6.6 7.2
F80
8 10.0 8.3 8.3 9.0
HA0
10 10.0 10.3 10.3 11.0
JA0
12.5 13.5 13.0 13.0 13.7
KE0
12.5 16.0 13.0 13.0 13.7
KG5
16 16.5 17.0 17.0 18.0
LH0
16 21.5 17.0 17.0 18.0
LN0
18 16.5 19.0 19.0 20.0
MH0
18 21.5 19.0 19.0 20.0
MN0
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
P
1.0
1.4
1.9
1.9
3.1
4.5
4.2
4.2
6.5
6.5
6.5
6.5
φD
±
0.5
φD
±
0.5
◆PART
NUMBERING SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
P
C
±
0.2
B
±
0.2
B
±
0.2
◆MARKING
D55 to JA0
EX) 16V47μF
7hA
P
C
±
0.2
E MV A
AAA A AA AAA
M
AAA N
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 1.0μF:1R0,100μF:101)
Taping·Tray code
Terminal code (A, G)
Voltage code (ex. 6.3V:6R3,100V:101,450V:451)
Series code
Category
KE0 to HN0
EX) 25V1,000μF
0V
MVA
47
16V
1000
25V
Please refer to "Product code guide (surface mount type)"
Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.
(1/2)
CAT. No. E1001M
