MGDT-35-0-CF/T-L datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> MGDT-35-0-CF/T-L

MGDT-35-0-CF/T-L: Description3-OUTPUT 20W DC-DC REG PWR SUPPLY MODULE, METAL PACKAGE-17; CategoryPower/power management The power supply circuit; File Size729KB，17 Pages; ManufacturerGAIA Converter Inc; Websitehttps://gaia-converter.com

Download Datasheet Parametric View All

MGDT-35-0-CF/T-L Overview

3-OUTPUT 20W DC-DC REG PWR SUPPLY MODULE, METAL PACKAGE-17

MGDT-35-0-CF/T-L Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	GAIA Converter Inc
Parts packaging code	MODULE
package instruction	,
Contacts	17
Reach Compliance Code	compliant
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	75 V
Minimum input voltage	16 V
Nominal input voltage	28 V
JESD-30 code	R-MDMA-P17
JESD-609 code	e3
length	82.5 mm
Maximum load regulation	2%
Number of functions	1
Output times	3
Number of terminals	17
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output voltage	5.102 V
Minimum output voltage	4.898 V
Nominal output voltage	5.1 V
Package body material	METAL
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN OVER NICKEL
Terminal form	PIN/PEG
Terminal pitch	5.08 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	20 W
Fine-tuning/adjustable output	YES
width	48.5 mm

Preview

Download Datasheet

View All

Hi-Rel DC/DC CONVERTER

MGDM-35 : 35W POWER

Hi-Rel

GradeGrade

4:1 Wide Input

Single, Bi & Triple Outputs

Metallic Case - 1.500 VDC Isolation

• 28Vdc input compliant with MIL-STD-740A/D/E/F

• Nominal power up to 35 W

• Wide temperature range : -40°C/+105°C case

• High efficiency (typ. 84%)

• Soft start

• Galvanic isolation 1.500 VDC

• Integrated LC input filter

• Permanent short circuit protection

• External synchronisation

• External trim and sense adjustment : +/-5%

• No optocoupler for high reliability

• RoHS or Leaded process option

1-General

The MGDM-35 wide input series is a full family of

DC/DC power modules designed for aerospace,

military and high-end industrial applications.

These modules use a high frequency fixed swiching

technic at 250KHz providing excellent reliability,

low noise characteristics and high power density.

Standard models are available with wide input

voltage range of 9-36, and 16-75. The serie

includes single, bi and triple output voltage choices

of 3.3, 5, 12, 15 volts.

No external heatsink is required for the

MGDM-35 series to supply 35W output power over

the full temperature range.

All the modules are designed with LC network

filters to minimize reflected input current ripple

and output voltage ripple .

The modules include a soft-start, an input

undervoltage lock-out, a permanent short cir-

cuit protection and an output overvoltage pro-

tection to ensure efficient module protections.

The soft-start allows current limitation and

eliminates inrush current during start-up. The

short circuit protection completely protects the

modules against short-circuits of any duration

by a shut-down and restores to normal when

the overload is removed.

The design has been carried out with surface

mount components and is manufactured in a

fully automated process to guarantee high

quality. Each module is tested with a GAIA

Converter automated test equipment.

2-Product Selection

Single output model

Bi output model

Triple output model

: MGDS - 35 -

: MGDB - 35 -

: MGDT - 35 -

input

output

option

suffix

Input Voltage Range

Permanent

Transient

B :

C :

E :

F :

BE :

BF :

CE :

CF :

Output

3.3 VDC

5 VDC or +/-5VDC

12 VDC or +/-12VDC

15 VDC or +/-15VDC

3.3 VDC and +/- 12 VDC

3.3 VDC and +/-15 VDC

5 VDC and +/- 12 VDC

5 VDC and +/-15 VDC

Suffix :

nothing : RoHS process

-L : leaded process

(available in N. America)

H :

O :

9-36 VDC

16-75 VDC

40 VDC/100 ms

80 VDC/100 ms

Options :

/T : option for -55°C start up operating temperature

/S : option for screening and serialization

REDEFINING THE SOURCE OF POWER

Gaia Converter FC045047.01/10 Revision C
