MVA5ALF2020AA-70.000MHZ datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> MVA5ALF2020AA-70.000MHZ

MVA5ALF2020AA-70.000MHZ: DescriptionOscillator,; CategoryPassive components oscillator; File Size101KB，2 Pages; ManufacturerMMD Monitor/Quartztek; Websitehttp://mmdcomp.com

Download Datasheet Parametric View All

MVA5ALF2020AA-70.000MHZ Overview

Oscillator,

MVA5ALF2020AA-70.000MHZ Parametric

Parameter Name	Attribute value
package instruction	DIP-14/5
Reach Compliance Code	compli
Other features	TRI-STATE; ENABLE/DISABLE FUNCTION
Maximum control voltage	2.25 V
Minimum control voltage	0.25 V
maximum descent time	2 ns
Frequency Adjustment - Mechanical	NO
Frequency offset/pull rate	200 ppm
frequency stability	20%
linearity	20%
Installation features	THROUGH HOLE MOUNT
Nominal operating frequency	70 MHz
Maximum operating temperature	70 °C
Minimum operating temperature
Oscillator type	LVPECL
Output load	50 OHM
physical size	20.7mm x 13.1mm x 8.5mm
longest rise time	2 ns
Maximum supply voltage	2.625 V
Minimum supply voltage	2.375 V
Nominal supply voltage	2.5 V
surface mount	NO
maximum symmetry	45/55 %
Base Number Matches	1

Preview

Download Datasheet

View All

MVAP, MVAL, and MVAV Series

Industry Standard Package

Wide Frequency Range

RoHS Compliant Available

Less than 1 pSec Jitter

ELECTRICAL SPECIFICATIONS:

Frequency Range

Frequency Stability*

Operating Temp.Range

Storage Temp. Range

Aging

Logic “0”

Logic “1”

+2.5VDC ± 5%

+3.3VDC ± 5%

+5.0VDC ± 5%

Symmetry (50% of waveform)

Rise / Fall Time (20% to 80%)

Load

Start Time

Phase Jitter (12kHz to 20MHz)

Supply Voltage (Vdd)

Supply Current

Tri-State Operation

* Inclusive of Temp., Load, Voltage and Aging

+2.5VDC

+3.3VDC

+5.0VDC

1.25VDC ±1.00VDC

1.65VDC ±1.50VDC

N/A

1.25VDC ±1.00VDC

N/A

1.65VDC ±1.50VDC

N/A

2.50VDC ±2.00VDC

(See Part Number Guide for Options)

LVPECL

PECL

70.000MHz to 800.000MHZ

(See Part Number Guide for Options)

-55°C to +125°C

±5 ppm / yr max

1.43V typ

Vdd – 1.620 VDC max

1.10V typ

Vdd- 1.025 vdc min

50 mA max

N/A

60 mA max

N/A

140 mA max

(See Part Number Guide for Options)

2nSec max

50 Ohms into Vdd-2.00 VDC

10mSec max

Less than 1 pSec

Vih = 70% of Vdd min to Enable Output

Vil = 30% max or grounded to Disable Output (High Impedance)

LVDS

Control Voltage (Vc)

Pullability

PART NUMBER GUIDE:

MVA

Frequency

14 Pin Dip VCXO

Output

P = PECL

L = LVPECL

V = LVDS

Package Options

5A = 14Pin Dip w/5 pins

6A = 14Pin Dip w/6 pins

Supply Voltage

2 = +2.5 VDC

3 = +3.3 VDC

5 = +5.0 VDC

RoHS Compliant

Blank = Not Compliant

F = is Compliant

Frequency

Stability

020 = ±20 ppm

025 = ±25 ppm

050 = ±50 ppm

100 = ±100 ppm

Symmetry

Blank = 40%/60%

A = 45%/55%

Operating

Temperature

Blank = 0°C to +70°C

27 = -20°C to +70°C

48 = -40°C to +85°C

Pullability

A = ±200 ppm min

C = ±100 ppm min

D = ±50 ppm min

P = ±25 ppm min

Linearity

Blank = ±20% max

X = ±5% max

Y = ±10% max

Z = ±15% max

MMD Components,

30400 Esperanza, Rancho Santa Margarita, CA, 92688

Phone: (949) 709-5075, Fax: (949) 709-3536,

www.mmdcomp.com

Sales@mmdcomp.com

Specifications subject to change without notice

Revision MVAP032907C
