CAT24M01YE-GT3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > storage> storage> CAT24M01YE-GT3

CAT24M01YE-GT3: Description128K X 8 SPI BUS SERIAL EEPROM, PDSO8; Categorystorage storage; File Size201KB，1 Pages; ManufacturerON Semiconductor; Websitehttp://www.onsemi.cn; Environmental Compliance

Download Datasheet Parametric Compare View All

CAT24M01YE-GT3 Overview

128K X 8 SPI BUS SERIAL EEPROM, PDSO8

CAT24M01YE-GT3 Parametric

Parameter Name	Attribute value
Brand Name	ON Semiconduc
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	TSSOP
package instruction	TSSOP, TSSOP8,.25
Contacts	8
Manufacturer packaging code	948AL
Reach Compliance Code	compli
ECCN code	EAR99
Maximum clock frequency (fCLK)	1 MHz
Data retention time - minimum	100
Durability	1000000 Write/Erase Cycles
I2C control byte	1010DDMR
JESD-30 code	R-PDSO-G8
JESD-609 code	e4
length	4.4 mm
memory density	1048576 bi
Memory IC Type	EEPROM
memory width	8
Humidity sensitivity level	1
Number of functions	1
Number of terminals	8
word count	131072 words
character code	128000
Operating mode	SYNCHRONOUS
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
organize	128KX8
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Encapsulate equivalent code	TSSOP8,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Parallel/Serial	SERIAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	2/5 V
Certification status	Not Qualified
Maximum seat height	1.2 mm
Serial bus type	SPI
Maximum standby current	0.000005 A
Maximum slew rate	0.003 mA
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	2.5 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3 mm
Maximum write cycle time (tWC)	5 ms
write protect	HARDWARE
Base Number Matches	1

Preview

Download Datasheet

View All

Product Overview

CAT24M01: EEPROM Serial 1-Mb I

For complete documentation, see the data sheet.

The CAT24M01 is a EEPROM Serial 1-Mb I C, internally organized as 131,072 words of 8 bits each.

It features a 256-byte page write buffer and supports the Standard (100 kHz), Fast (400 kHz) and Fast-Plus (1 MHz) I2C protocol.

Write operations can be inhibited by taking the WP pin High (this protects the entire memory).

External address pins make it possible to address up to four CAT24M01 devices on the same bus.

On-Chip ECC (Error Correction Code) makes the device suitable for high reliability applications.

Features

• Supports Standard, Fast and Fast-Plus I C Protocol

• 1.8 V to 5.5 V Supply Voltage Range

• 256-Byte Page Write Buffer

• Hardware Write Protection for Entire Memory

• Schmitt Triggers and Noise Suppression Filters on I C Bus

Inputs (SCL and SDA)

• Low Power CMOS Technology

• 1,000,000 Program/Erase Cycles

• 100 Year Data Retention

• Industrial and Extended Temperature Range

• 8-pin PDIP, SOIC, TSSOP and 8pad UDFN Packages

For more features, see the data sheet

Benefits

• Simple interface protocol / industry standard; 1MHz clock

enables faster operation.

• Single power supply from 1.8V to 5.5V: allows multiple

applications / various VCC values using the same device.

Part Electrical Specifications

Product

Compliance

Status

Type

Densit

Organi Data

zation Trans

missio

Stand

ard

128k x

I2C

cycle

Max

(kHz)

ACC

Max

Min

(V)

Max

(V)

standby

Max

(µA)

act

Max

(mA)

T Min

(°C)

T Max

(°C)

Packa

Type

CAT24M01HU5I-GT3

Pb-free

Halide free

Active

Serial

1 Mb

1000

400

1.8

5.5

-40

UDFN-

SOIC-

TSSO

P-8

TSSO

P-8

CAT24M01WE-GT3

Pb-free

Halide free

Active

Serial

1 Mb

I2C

400

900

2.5

5.5

-40

125

CAT24M01WI-GT3

Pb-free

Halide free

Active

Serial

1 Mb

I2C

1000

400

1.8

5.5

-40

CAT24M01XI-T2

Pb-free

Halide free

Active

Serial

1 Mb

I2C

1000

400

1.8

5.5

-40

CAT24M01YE-GT3

Pb-free

Halide free

Active

Serial

1 Mb

I2C

400

900

2.5

5.5

-40

125

CAT24M01YI-GT3

Pb-free

Halide free

Active

Serial

1 Mb

I2C

1000

400

1.8

5.5

-40

For more information please contact your local sales support at www.onsemi.com.

Created on: 12/2/2018

CAT24M01YE-GT3 Related Products

	CAT24M01YE-GT3	CAT24M01LE-G	CAT24M01WE-GT3	CAT24M01XE-T2
Description	128K X 8 SPI BUS SERIAL EEPROM, PDSO8	128K X 8 SPI BUS SERIAL EEPROM, PDSO8	128K X 8 SPI BUS SERIAL EEPROM, PDSO8	128K X 8 SPI BUS SERIAL EEPROM, PDSO8
Is it lead-free?	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to
Parts packaging code	TSSOP	DIP	SOIC	SOIC
package instruction	TSSOP, TSSOP8,.25	DIP, DIP8,.3	SOP, SOP8,.25	0.208 INCH, HALOGEN FREE AND ROHS COMPLIANT, SOIC-8
Contacts	8	8	8	8
Reach Compliance Code	compli	compli	compli	compli
ECCN code	EAR99	EAR99	EAR99	EAR99
Maximum clock frequency (fCLK)	1 MHz	1 MHz	1 MHz	1 MHz
Data retention time - minimum	100	100	100	100
Durability	1000000 Write/Erase Cycles	1000000 Write/Erase Cycles	1000000 Write/Erase Cycles	1000000 Write/Erase Cycles
I2C control byte	1010DDMR	1010DDMR	1010DDMR	1010DDMR
JESD-30 code	R-PDSO-G8	R-PDIP-T8	R-PDSO-G8	R-PDSO-G8
JESD-609 code	e4	e4	e4	e3
length	4.4 mm	9.27 mm	4.9 mm	5.255 mm
memory density	1048576 bi	1048576 bi	1048576 bi	1048576 bi
Memory IC Type	EEPROM	EEPROM	EEPROM	EEPROM
memory width	8	8	8	8
Number of functions	1	1	1	1
Number of terminals	8	8	8	8
word count	131072 words	131072 words	131072 words	131072 words
character code	128000	128000	128000	128000
Operating mode	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C
organize	128KX8	128KX8	128KX8	128KX8
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TSSOP	DIP	SOP	SOP
Encapsulate equivalent code	TSSOP8,.25	DIP8,.3	SOP8,.25	SOP8,.3
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	IN-LINE	SMALL OUTLINE	SMALL OUTLINE
Parallel/Serial	SERIAL	SERIAL	SERIAL	SERIAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	260	NOT SPECIFIED
power supply	2/5 V	2/5 V	2/5 V	2/5 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.2 mm	5.33 mm	1.75 mm	2.03 mm
Serial bus type	SPI	SPI	SPI	SPI
Maximum standby current	0.000005 A	0.000005 A	0.000005 A	0.000005 A
Maximum slew rate	0.003 mA	0.003 mA	0.003 mA	0.003 mA
Maximum supply voltage (Vsup)	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	2.5 V	2.5 V	2.5 V	2.5 V
Nominal supply voltage (Vsup)	3.3 V	3.3 V	3.3 V	3.3 V
surface mount	YES	NO	YES	YES
technology	CMOS	CMOS	CMOS	CMOS
Temperature level	AUTOMOTIVE	AUTOMOTIVE	AUTOMOTIVE	AUTOMOTIVE
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)	NICKEL PALLADIUM GOLD	Nickel/Palladium/Gold (Ni/Pd/Au)	MATTE TIN
Terminal form	GULL WING	THROUGH-HOLE	GULL WING	GULL WING
Terminal pitch	0.65 mm	2.54 mm	1.27 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	40	NOT SPECIFIED
width	3 mm	7.62 mm	3.9 mm	5.23 mm
Maximum write cycle time (tWC)	5 ms	5 ms	5 ms	5 ms
write protect	HARDWARE	HARDWARE	HARDWARE	HARDWARE
Maker	-	ON Semiconductor	ON Semiconductor	ON Semiconductor
