Lead (Pb)-free solder contacts on Ni barrier layer
•
Pure tin plating provides compatibility with lead (Pb)-free
and lead containing soldering processes
•
Metal glaze on high quality ceramic
•
Protective overglaze
STANDARD ELECTRICAL SPECIFICATIONS
SIZE
MODEL
INCH METRIC
POWER RATING
P
70 °C
W
0.05
LIMITING
ELEMENT
VOLTAGE
MAX V≅
30
RESISTANCE
TEMPERATURE
TOLERANCE
RANGE
E-SERIES
COEFFICIENT
%
Ω
ppm/K
± 100
± 200
±1
± 1; ± 5
47R - 1M0
10R - 1M0
24 + 96
24
CRCW0201
0201
0525
Zero-Ohm-Resistor:
R
max
= 50 mΩ,
I
max
at 70 °C = 1.0 A
D10/CRCW0402
0402
1005
0.063
50
± 100
± 200
±1
±5
1R0 - 10M
24 + 96
24
Zero-Ohm-Resistor:
R
max
= 20 mΩ,
I
max
at 70 °C = 1.5 A
D11/CRCW0603
0603
1608
0.10
75
± 100
± 200
± 100
± 200
±1
±5
±1
±5
1R0 - 10M
24 + 96
24
24 + 96
24
Zero-Ohm-Resistor:
R
max
= 20 mΩ,
I
max
at 70 °C = 2.0 A
D12/CRCW0805
0805
2012
0.125
150
1R0 - 10M
Zero-Ohm-Resistor:
R
max
= 20 mΩ,
I
max
at 70 °C = 2.5 A
D25/CRCW1206
1206
3216
0.25
200
± 100
± 200
±1
±5
1R0 - 10M
24 + 96
24
Zero-Ohm-Resistor:
R
max
= 20 mΩ,
I
max
at 70 °C = 3.5 A
CRCW1210
1210
3225
0.33
200
± 100
± 200
± 100
± 200
±1
±5
±1
±5
1R0 - 10M
24 + 96
24
24 + 96
24
Zero-Ohm-Resistor:
R
max
= 20 mΩ,
I
max
at 70 °C = 4.0 A
CRCW1218
1218
3246
1.0
200
1R0 - 2M2
Zero-Ohm-Resistor:
R
max
= 20 mΩ,
I
max
at 70 °C = 7.0 A
CRCW2010
2010
5025
0.50
400
± 100
± 200
± 100
± 200
±1
±5
±1
±5
1R0 - 10M
24 + 96
24
24 + 96
24
Zero-Ohm-Resistor:
R
max
= 20 mΩ,
I
max
at 70 °C = 5.0 A
CRCW2512
2512
6332
1.0
500
1R0 - 10M
Zero-Ohm-Resistor:
R
max
= 20 mΩ,
I
max
at 70 °C = 7.0 A
Notes
•
These resistors do not feature a limited lifetime when operated within the permissible limits. However, resistance value drift increasing over
operating time may result in exceeding a limit acceptable to the specific application, thereby establishing a functional lifetime
•
Marking and packaging: see appropriate catalog or web pages
•
Power rating depends on the max. temperature at the solder point, the component placement density and the substrate material
Document Number: 20035
Revision: 04-Jul-07
For technical questions in Europe, contact: ff3cresistors@vishay.com
For technical questions in Americas/Asia, contact: ff2bresistors@vishay.com
www.vishay.com
107
D../CRCW.... e3
Vishay
Lead (Pb)-free Thick Film, Rectangular Chip Resistors
TECHNICAL SPECIFICATIONS
PARAMETER
Rated Dissipation at 70 °C
3)
Limiting Element Voltage
2)
Insulation Voltage (1 min)
Thermal Resistance
1)
Insulation Resistance
Category Temperature Range
Failure Rate
Weight/1000 pcs
Notes
1. For sizes 0402 until 1206 the measuring conditions are in acc. to EN 140401-802. For all other sizes the result depends on the solder pad dimensions.
2. Rated voltage:
PxR
3. The power dissipation on the resistor generates a temperature rise against the local ambient, depending on the heat flow support of the
printed-circuit board (thermal resistance). The rated dissipation applies only if the permitted film temperature of 155 °C is not exceeded.
