技术信息/TechnicalInformation
IGBT-模块
IGBT-modules
DD800S17K3_B2
初步数据
PreliminaryData
二极管,逆变器/Diode,Inverter
反向重复峰值电压
Repetitivepeakreversevoltage
连续正向直流电流
ContinuousDCforwardcurrent
正向重复峰值电流
Repetitivepeakforwardcurrent
I2t-值
I²t-value
最大额定值/MaximumRatedValues
T
vj
= 25°C
t
P
= 1 ms
V
R
= 0 V, t
P
= 10 ms, T
vj
= 125°C
V
RRM
I
F
I
FRM
I²t
min.
I
F
= 800 A, V
GE
= 0 V
I
F
= 800 A, V
GE
= 0 V
T
vj
= 25°C
T
vj
= 125°C
V
F
I
RM
1700
800
1600
125
typ.
1,80
1,90
780
850
205
345
130
225
16,0
max.
2,20
V
V
A
A
µC
µC
mJ
mJ
V
A
A
kA²s
特征值/CharacteristicValues
正向电压
Forwardvoltage
反向恢复峰值电流
Peakreverserecoverycurrent
恢复电荷
Recoveredcharge
反向恢复损耗（每脉冲）
Reverserecoveryenergy
结－壳热阻
Thermalresistance,junctiontocase
壳－散热器热阻
Thermalresistance,casetoheatsink
I
F
= 800 A, - di
F
/dt = 4900 A/µs (T
vj
=125°C) T
vj
= 25°C
V
R
= 900 V
T
vj
= 125°C
V
GE
= -15 V
I
F
= 800 A, - di
F
/dt = 4900 A/µs (T
vj
=125°C) T
vj
= 25°C
V
R
= 900 V
T
vj
= 125°C
V
GE
= -15 V
I
F
= 800 A, - di
F
/dt = 4900 A/µs (T
vj
=125°C) T
vj
= 25°C
V
R
= 900 V
T
vj
= 125°C
V
GE
= -15 V
每个二极管/perdiode
每个二极管/perdiode
λ
Paste
=1W/(m·K)/λ
grease
=1W/(m·K)
Q
r
E
rec
R
thJC
R
thCH
43,0 K/kW
K/kW
preparedby:WB
approvedby:PL
dateofpublication:2013-04-30
revision:2.2
1
技术信息/TechnicalInformation
IGBT-模块
IGBT-modules
DD800S17K3_B2
初步数据
PreliminaryData
模块/Module
绝缘测试电压
Isolationtestvoltage
模块基板材料
Materialofmodulebaseplate
内部绝缘材料
Internalisolation
爬电距离
Creepagedistance
电气间隙
Clearance
相对电痕指数
Comperativetrackingindex
壳－散热器热阻
Thermalresistance,casetoheatsink
杂散电感,模块
Strayinductancemodule
模块引线电阻,端子-芯片
Moduleleadresistance,terminals-chip
最大结温
Maximumjunctiontemperature
在开关状态下温度
Temperatureunderswitchingconditions
储存温度
Storagetemperature
模块安装的安装扭距
Mountingtorqueformodulmounting
端子联接扭距
Terminalconnectiontorque
重量
Weight
RMS, f = 50 Hz, t = 1 min.
基本绝缘(class1,IEC61140)
basicinsulation(class1,IEC61140)
如½与取得联系-散热片/terminaltoheatsink
如½与取得联系-如½与取得联系/terminaltoterminal
如½与取得联系-散热片/terminaltoheatsink
如½与取得联系-如½与取得联系/terminaltoterminal
每个模块/permodule
λ
Paste
=1W/(m·K)/λ
grease
=1W/(m·K)
T
C
=25°C,每个开关/perswitch
逆变器,制动-斩波器/inverter,brake-chopper
逆变器,制动-斩波器/inverter,brake-chopper
螺丝M6根据相应的应用手册进行安装
ScrewM6-Mountingaccordingtovalidapplicationnote
螺丝M8根据相应的应用手册进行安装
ScrewM8-Mountingaccordingtovalidapplicationnote
V
ISOL
CTI
min.
R
thCH
L
sCE
R
AA'+CC'
T
vj max
T
vj op
T
stg
M
M
8,0
G
-
1050
10
Nm
g
-40
-40
4,25
1,8
4,0
AlSiC
AlN
32,2
19,1
> 400
typ.
8,00
25
0,37
-
-
150
125
125
5,75
2,1
max.
K/kW
nH
mΩ
°C
°C
°C
Nm
Nm
kV
mm
mm
DynamischeDatengelteninVerbindungmitFF800R17KE3Modul
DynamicdatavalidinconjunctionwithFF800R17KE3module
preparedby:WB
approvedby:PL
dateofpublication:2013-04-30
revision:2.2
2
技术信息/TechnicalInformation
IGBT-模块
IGBT-modules
DD800S17K3_B2
初步数据
PreliminaryData
开关损耗二极管,逆变器（典型)
switchinglossesDiode,Inverter(typical)
E
rec
=f(I
F
)
R
Gon
=Ω,V
CE
=900V
275
正向偏压特性二极管,逆变器（典型)
forwardcharacteristicofDiode,Inverter(typical)
I
F
=f(V
F
)
1600
1400
1200
1000
800
600
400
200
0
T
vj
= 25°C
T
vj
= 125°C
E
rec
, T
vj
= 125°C
250
225
200
175
E [mJ]
150
125
100
75
50
25
0
I
F
[A]
0,0
0,5
1,0
1,5
V
F
[V]
2,0
2,5
3,0
0
200
400
600
800 1000 1200 1400 1600
I
F
[A]
开关损耗二极管,逆变器（典型)
switchinglossesDiode,Inverter(typical)
E
rec
=f(R
G
)
I
F
=800A,V
CE
=900V
300
275
250
225
200
E
rec
, T
vj
= 125°C
瞬态热阻抗二极管,逆变器
transientthermalimpedanceDiode,Inverter
Z
thJC
=f(t)
100
Z
thJC
: Diode
150
125
100
75
50
25
0
0
2
4
6
8
10
R
G
[Ω]
12
14
16
18
Z
thJC
[K/kW]
175
E [mJ]
10
i:
1
2
3
4
r
i
[K/kW]: 8,6 8,6 17,2 8,6
τ
i
[s]:
0,01 0,04 0,09 0,2
1
0,001
0,01
t [s]
0,1
1
preparedby:WB
approvedby:PL
dateofpublication:2013-04-30
revision:2.2
3
技术信息/TechnicalInformation
IGBT-模块
IGBT-modules
DD800S17K3_B2
初步数据
PreliminaryData
接线图/circuit_diagram_headline
封装尺寸/packageoutlines
preparedby:WB
approvedby:PL
dateofpublication:2013-04-30
revision:2.2
4
技术信息/TechnicalInformation
IGBT-模块
IGBT-modules
DD800S17K3_B2
初步数据
PreliminaryData
½用条件和条款
½用条件和条款
产品规格书中的数据是专门为技术人员提供的，您和您的技术部门应该针对您的应用来评估产品及产品的所有参数是否适合
产品规格书中所描述的产品特性是被保证的，任½这种保证严格依照供货协议中所涉及的条件和条款。
除此之外，产品和产品的特性没有任½的保证
请注意安装及应用指南中的信息。
如果您有超出规格书所提供的产品信息的要求或者对我们的产品针对的特殊应用有疑虑的话，请联系我们的销售部，他们将对您负责
（详情查询www.infineon.com）。对那些特别感兴趣的问题我们将提供相应的应用手册
由于技术需要，我们的产品可½含有危险物质。如果需要查询类似问题请联系我们的销售部，他们将对您负责
如果您想将我们的产品用于航天，健康，危及生½或者生½维持等应用，请申明。
请注意，对这类应用我们强烈建议
-执行联合的风险和质量评估
-得到质量协议的结论
-建立联合的测试和出厂产品检查，我们可以根据测试的实际情况供货
如果有必要，请根据实际需要将类似的说明给½的客户
保留产品规格书的修改权
Terms&Conditionsofusage
Thedatacontainedinthisproductdatasheetisexclusivelyintendedfortechnicallytrainedstaff.Youandyourtechnicaldepartmentswill
havetoevaluatethesuitabilityoftheproductfortheintendedapplicationandthecompletenessoftheproductdatawithrespecttosuch
application.
Thisproductdatasheetisdescribingthecharacteristicsofthisproductforwhichawarrantyisgranted.Anysuchwarrantyisgranted
exclusivelypursuantthetermsandconditionsofthesupplyagreement.Therewillbenoguaranteeofanykindfortheproductandits
characteristics.Theinformationinthevalidapplication-andassemblynotesofthemodulemustbeconsidered.
Shouldyourequireproductinformationinexcessofthedatagiveninthisproductdatasheetorwhichconcernsthespecificapplicationof
ourproduct,pleasecontactthesalesoffice,whichisresponsibleforyou(seewww.infineon.com).Forthosethatarespecifically
interestedwemayprovideapplicationnotes.
Duetotechnicalrequirementsourproductmaycontaindangeroussubstances.Forinformationonthetypesinquestionpleasecontactthe
salesoffice,whichisresponsibleforyou.
ShouldyouintendtousetheProductinaviationapplications,inhealthorliveendangeringorlifesupportapplications,pleasenotify.Please
note,thatforanysuchapplicationsweurgentlyrecommend
-toperformjointRiskandQualityAssessments;
-theconclusionofQualityAgreements;
-toestablishjointmeasuresofanongoingproductsurvey,andthatwemaymakedeliverydependedon
therealizationofanysuchmeasures.
Ifandtotheextentnecessary,pleaseforwardequivalentnoticestoyourcustomers.
Changesofthisproductdatasheetarereserved.
