AD7501JN datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> AD7501JN

AD7501JN: Description8-CHANNEL, SGL ENDED MULTIPLEXER, PDIP16, PLASTIC, DIP-16; CategoryAnalog mixed-signal IC The signal circuit; File Size768KB，3 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Related ProductsFound8parts with similar functions to AD7501JN

Download Datasheet Parametric Compare View All

AD7501JN Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AD7501JN	-	-	View	Buy Now

AD7501JN Overview

8-CHANNEL, SGL ENDED MULTIPLEXER, PDIP16, PLASTIC, DIP-16

AD7501JN Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	PLASTIC, DIP-16
Contacts	16
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER
JESD-30 code	R-PDIP-T16
JESD-609 code	e0
length	19.05 mm
Humidity sensitivity level	NOT APPLICABLE
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	8
Number of functions	1
Number of terminals	16
On-state resistance matching specifications	6.8 Ω
Maximum on-state resistance (Ron)	300 Ω
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
Certification status	COMMERCIAL
Maximum seat height	5.33 mm
Nominal supply voltage (Vsup)	15 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE
width	7.62 mm
