Document 378-1
Shielded Power Inductors – MSS1038
• 10.0 × 10.2 mm footprint; 3.8 mm high shielded inductors
• Very low DCR and excellent current handling
Designer’s Kit C391
contains 3 each of all values.
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Terminations
RoHS compliant matte tin over nickel over copper.
Other terminations available at additional cost.
Weight:
1.5 g
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
250/7″ reel; 1000/13″ reel; Plastic tape: 24 mm wide,
0.35 mm thick, 16 mm pocket spacing, 4.3 mm pocket depth
PCB washing
Tested with pure water or alcohol only. For other
solvents, see Doc787_PCB_Washing.pdf.
DCR
Inductance
2
max
Part number
1
(µH)
(m)
MSS1038-102NL_
1.0 ±30%
6.0
MSS1038-152NL_
1.5 ±30%
8.1
MSS1038-252NL_
2.5 ±30% 10
MSS1038-382NL_
3.8 ±30% 13
MSS1038-522NL_
5.2 ±30% 22
MSS1038-702NL_
7.0 ±30% 27
MSS1038-103NL_ 10 ±30%
35
MSS1038-123ML_ 12 ±20%
41
MSS1038-153ML_ 15 ±20%
50
MSS1038-183ML_ 18 ±20%
65
MSS1038-223ML_ 22 ±20%
73
MSS1038-273ML_ 27 ±20%
89
MSS1038-333ML_ 33 ±20%
93
MSS1038-393ML_ 39 ±20% 112
MSS1038-473ML_ 47 ±20% 128
MSS1038-563ML_ 56 ±20% 180
MSS1038-683ML_ 68 ±20% 213
MSS1038-823ML_ 82 ±20% 261
MSS1038-104ML_ 100 ±20% 304
MSS1038-124KL_ 120 ±10% 380
MSS1038-154KL_ 150 ±10% 506
MSS1038-184KL_ 180 ±10% 582
MSS1038-224KL_ 220 ±10% 756
MSS1038-274KL_ 270 ±10% 926
MSS1038-334KL_ 330 ±10% 1090
MSS1038-394KL_ 390 ±10% 1141
MSS1038-474KL_ 470 ±10% 1243
MSS1038-564KL_ 560 ±10% 1696
MSS1038-684KL_ 680 ±10% 1926
MSS1038-824KL_ 820 ±10% 2596
MSS1038-105KL_ 1000 ±10% 2853
Isat
(A)
4
SRF
typ
3
10% 20% 30%
(MHz) drop drop drop
138
9.00 11.16 12.10
81
7.40 9.48 11.06
61
5.70 7.62 9.26
45
4.94 6.50 7.64
37
3.96 5.28 6.14
33
3.62 4.74 5.60
29
3.04 3.90 4.52
25
2.72 3.48 4.04
21
2.84 3.44 3.86
18
2.44 3.10 3.52
15
2.34 2.94 3.30
15
1.98 2.48 2.84
13
1.84 2.34 2.62
12
1.60 2.04 2.34
11
1.60 1.98 2.22
11
1.48 1.84 2.04
10
1.32 1.62 1.82
8
1.12 1.42 1.60
6
1.02 1.30 1.46
6
0.95 1.18 1.34
6
0.89 1.10 1.22
5
0.89 1.02 1.16
5
0.72 0.88 0.99
4
0.66 0.81 0.91
4
0.59 0.73 0.82
4
0.51 0.65 0.74
3
0.50 0.62 0.70
3
0.43 0.53 0.56
3
0.38 0.48 0.52
3
0.37 0.46 0.49
3
0.35 0.43 0.46
Irms
(A)
5
20°C 40°C
rise rise
7.30 10.00
5.60 7.85
4.65 6.65
4.25 6.05
3.60 5.10
3.10 4.35
2.90 4.05
2.85 4.00
2.70 3.80
2.25 3.35
1.90 2.85
1.65 2.35
1.60 2.30
1.55 2.25
1.45 2.20
1.40 1.85
1.15 1.75
1.09 1.50
1.05 1.45
0.85 1.25
0.80 1.20
0.71 0.98
0.70 0.97
0.65 0.86
0.50 0.69
0.49 0.65
0.45 0.63
0.43 0.59
0.36 0.50
0.34 0.47
0.33 0.45
1. Please specify
termination
and
packaging
codes:
MSS1038-105KLC
Termination: L
= RoHS compliant matte tin over nickel
over copper.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481
embossed plastic tape (250 parts
per full reel).
B
= Less than full reel. In tape, but not
machine ready. To have a leader
and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481
embossed plastic tape. Factory
order only, not stocked (1000 parts
per full reel).
2. Inductance measured at 100 kHz, 0.1 Vrms, 0 Adc
using an Agilent/HP 4263B LCR meter or equivalent.
3. SRF measured using an Agilent/HP 8753D or equivalent.
4. DC current at which the inductance drops the speci-
fied amount from its value without current.
5. Current that causes the specified temperature rise
from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 378-1
Revised 08/01/11
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
