SG55473Y/883B datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> SG55473Y/883B

Preview

SG55473Y/883B: DescriptionOR Gate Based Peripheral Driver, 0.4A, BIPolar, CDIP8; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size111KB，3 Pages; ManufacturerMicrosemi; Websitehttps://www.microsemi.com

Download Datasheet Parametric Compare View All

SG55473Y/883B Overview

OR Gate Based Peripheral Driver, 0.4A, BIPolar, CDIP8

SG55473Y/883B Parametric

Parameter Name	Attribute value
Maker	Microsemi
Parts packaging code	DIP
package instruction	,
Contacts	8
Reach Compliance Code	unknown
ECCN code	EAR99
Input properties	STANDARD
Interface integrated circuit type	OR GATE BASED PERIPHERAL DRIVER
JESD-30 code	R-GDIP-T8
Number of functions	2
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output characteristics	OPEN-COLLECTOR
Output current flow direction	SINK
Nominal output peak current	0.4 A
Package body material	CERAMIC, GLASS-SEALED
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Maximum slew rate	76 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	NO
technology	BIPOLAR
Temperature level	MILITARY
Terminal form	THROUGH-HOLE
Terminal location	DUAL
Disconnect time	0.055 µs
connection time	0.04 µs

Preview

Download Datasheet

View All

This Material Copyrighted By Its Respective Manufacturer

SG55473Y/883B Related Products

	SG55473Y/883B	SG55463L/883B	SG55473L/883B	SG55453BY	SG55453BY/883B	SG55453BL	SG55473Y	SG55473L
Description	OR Gate Based Peripheral Driver, 0.4A, BIPolar, CDIP8	OR Gate Based Peripheral Driver, 0.4A, BIPolar, CQCC20	OR Gate Based Peripheral Driver, 0.4A, BIPolar, CQCC20	OR Gate Based Peripheral Driver, CDIP8, CERAMIC, DIP-8	OR Gate Based Peripheral Driver, CDIP8, CERAMIC, DIP-8	OR Gate Based Peripheral Driver, 0.4A, BIPolar, CQCC20	OR Gate Based Peripheral Driver, 0.4A, BIPolar, CDIP8	OR Gate Based Peripheral Driver, 0.4A, BIPolar, CQCC20
Parts packaging code	DIP	QLCC	QLCC	DIP	DIP	QLCC	DIP	QLCC
Contacts	8	20	20	8	8	20	8	20
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Input properties	STANDARD	STANDARD	STANDARD	STANDARD	STANDARD	STANDARD	STANDARD	STANDARD
Interface integrated circuit type	OR GATE BASED PERIPHERAL DRIVER	OR GATE BASED PERIPHERAL DRIVER	OR GATE BASED PERIPHERAL DRIVER	OR GATE BASED PERIPHERAL DRIVER	OR GATE BASED PERIPHERAL DRIVER	OR GATE BASED PERIPHERAL DRIVER	OR GATE BASED PERIPHERAL DRIVER	OR GATE BASED PERIPHERAL DRIVER
JESD-30 code	R-GDIP-T8	S-CQCC-N20	S-CQCC-N20	R-GDIP-T8	R-GDIP-T8	S-CQCC-N20	R-GDIP-T8	S-CQCC-N20
Number of functions	2	2	2	2	2	2	2	2
Number of terminals	8	20	20	8	8	20	8	20
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Output characteristics	OPEN-COLLECTOR	OPEN-COLLECTOR	OPEN-COLLECTOR	OPEN-COLLECTOR	OPEN-COLLECTOR	OPEN-COLLECTOR	OPEN-COLLECTOR	OPEN-COLLECTOR
Output current flow direction	SINK	SINK	SINK	SINK	SINK	SINK	SINK	SINK
Nominal output peak current	0.4 A	0.4 A	0.4 A	0.4 A	0.4 A	0.4 A	0.4 A	0.4 A
Package body material	CERAMIC, GLASS-SEALED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, GLASS-SEALED	CERAMIC, GLASS-SEALED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, GLASS-SEALED	CERAMIC, METAL-SEALED COFIRED
Package shape	RECTANGULAR	SQUARE	SQUARE	RECTANGULAR	RECTANGULAR	SQUARE	RECTANGULAR	SQUARE
Package form	IN-LINE	CHIP CARRIER	CHIP CARRIER	IN-LINE	IN-LINE	CHIP CARRIER	IN-LINE	CHIP CARRIER
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum slew rate	76 mA	76 mA	76 mA	68 mA	68 mA	68 mA	76 mA	76 mA
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	NO	YES	YES	NO	NO	YES	NO	YES
technology	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR
Temperature level	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY
Terminal form	THROUGH-HOLE	NO LEAD	NO LEAD	THROUGH-HOLE	THROUGH-HOLE	NO LEAD	THROUGH-HOLE	NO LEAD
Terminal location	DUAL	QUAD	QUAD	DUAL	DUAL	QUAD	DUAL	QUAD
Disconnect time	0.055 µs	0.055 µs	0.055 µs	0.025 µs	0.025 µs	0.025 µs	0.055 µs	0.055 µs
connection time	0.04 µs	0.04 µs	0.04 µs	0.025 µs	0.025 µs	0.025 µs	0.04 µs	0.04 µs
Maker	Microsemi	Microsemi	-	Microsemi	Microsemi	Microsemi	Microsemi	Microsemi
