PS2913-1-F4-N datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> PS2913-1-F4-N

PS2913-1-F4-N: DescriptionTransistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4; CategoryLED optoelectronic/LED photoelectric; File Size347KB，10 Pages; ManufacturerNEC Electronics

Download Datasheet Parametric Compare View All

PS2913-1-F4-N Overview

Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4

PS2913-1-F4-N Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	NEC Electronics
package instruction	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4
Reach Compliance Code	compliant
Coll-Emtr Bkdn Voltage-Min	120 V
Configuration	SINGLE
Nominal current transfer ratio	50%
Maximum dark power	100 nA
Maximum forward current	0.05 A
Maximum insulation voltage	2500 V
JESD-609 code	e0
Number of components	1
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
Optoelectronic device types	TRANSISTOR OUTPUT OPTOCOUPLER
Terminal surface	Tin/Lead (Sn/Pb)

Preview

Download Datasheet

View All

PHOTOCOUPLER

PS2913-1

SINGLE Tr. OUTPUT, HIGH COLLECTOR TO EMITTER VOLTAGE

4-PIN ULTRA SMALL FLAT-LEAD

−NEPOC

Series−

PHOTOCOUPLER

DESCRIPTION

The PS2913-1 is an optically coupled isolator containing a GaAs light emitting diode and an NPN silicon

phototransistor in one package for high density mounting applications.

An ultra small flat-lead package has been provided which realizes a reduction in mounting area of about 30%

compared with the PS28xx series.

FEATURES

• Ultra small flat-lead package (4.6 (L)

2.5 (W)

2.1 (H) mm)

• Isolation distance (0.4 mm MIN.)

• High collector to emitter voltage (V

CEO

= 120 V)

• High isolation voltage (BV = 2 500 Vr.m.s.)

• Ordering number of taping product: PS2913-1-F3, F4: 3 500 pcs/reel

APPLICATIONS

• Hybrid IC

• Power supply

Document No. PN10043EJ02V0DS (2nd edition)

Date Published November 2003 CP(K)

The mark

shows major revised points.

PS2913-1-F4-N Related Products

	PS2913-1-F4-N	PS2913-1-F3-K	PS2913-1-F4-K	PS2913-1-F3	PS2913-1-F3-L	PS2913-1-F3-M	PS2913-1-F3-N	PS2913-1-F4-L
Description	Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	Transistor Output Optocoupler, 1-Element, 2500V Isolation, 4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4
Maker	NEC Electronics	NEC Electronics	NEC Electronics	NEC Electronics	NEC Electronics	NEC Electronics	NEC Electronics	NEC Electronics
package instruction	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4	4.60 X 2.50 MM, 2.10 MM HEIGHT, ULTRA SMALL, PACKAGE-4
Reach Compliance Code	compliant	compliant	compliant	unknown	compliant	compliant	compliant	compliant
Coll-Emtr Bkdn Voltage-Min	120 V	120 V	120 V	120 V	120 V	120 V	120 V	120 V
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Nominal current transfer ratio	50%	100%	100%	100%	75%	50%	50%	75%
Maximum dark power	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA
Maximum forward current	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A
Maximum insulation voltage	2500 V	2500 V	2500 V	2500 V	2500 V	2500 V	2500 V	2500 V
Number of components	1	1	1	1	1	1	1	1
Maximum operating temperature	100 °C	100 °C	100 °C	100 °C	100 °C	100 °C	100 °C	100 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Optoelectronic device types	TRANSISTOR OUTPUT OPTOCOUPLER	TRANSISTOR OUTPUT OPTOCOUPLER	TRANSISTOR OUTPUT OPTOCOUPLER	TRANSISTOR OUTPUT OPTOCOUPLER	TRANSISTOR OUTPUT OPTOCOUPLER	TRANSISTOR OUTPUT OPTOCOUPLER	TRANSISTOR OUTPUT OPTOCOUPLER	TRANSISTOR OUTPUT OPTOCOUPLER
Is it Rohs certified?	incompatible	incompatible	incompatible	-	incompatible	incompatible	incompatible	incompatible
JESD-609 code	e0	e0	e0	-	e0	e0	e0	e0
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
