3.3V TRI-STATE ENABLE/DISABLE OSCILLATORS
MODEL: F5C-2E3
FEATURES
•
•
•
•
3.3V Operation
HCMOS Output
Tri-State Enable/Disable
14-Pin DIP
OPTIONS
• 8-Pin DIP Available (H5C-2E3)
Discontinued
Model Number
F5C-2E3
F5C-2E3R
F6C-2E3
F6C-2E3R
F7C-2E3
F7C-2E3R
F8C-2E3
Frequency
Frequency
Operating
Stability
1
Temperature(ºC) Range (MHz)
1.000~160.000
±100PPM
0 ~ +70
1.000~160.000
±100PPM
-40 ~ +85
1.000~160.000
±50PPM
0 ~ +70
1.000~160.000
±50PPM
-40 ~ +85
1.000~160.000
±25PPM
0 ~ +70
1.000~125.000
±25PPM
-40 ~ +85
1.000~125.000
±20PPM
0 ~ +70
Internet required
• PART NUMBER SELECTION
Learn More - Internet Required
Part Number
148-Frequency-xxxxx
355-Frequency-xxxxx
328-Frequency-xxxxx
356-Frequency-xxxxx
329-Frequency-xxxxx
358-Frequency-xxxxx
567-Frequency-xxxxx
Learn more about:
Part Marking Identification
Mechanical Specification
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.000 ~ 23.999 MHz
24.000 ~ 49.999 MHz
50.000 ~ 69.999 MHz
70.000 ~ 125.000 MHz
125.000 ~ 160.000 MHz
Output Symmetry (50% V
dd
)
Rise Time (10% ~ 90% V
dd
) (T
r
)
Fall Time (90% ~ 10% V
dd
) (T
f
)
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
(HCMOS)
Start-up Time
(T
s
)
Output Enable/Disable Time
2
1
MAX
(unless otherwise noted)
1.000 ~ 160.000 MHz
-55ºC ~ +125ºC
3.3V ± 10%
15mA
20mA
40mA
45mA
60mA
40% ~ 60%
10 nS
10 nS
10% V
dd
90% V
dd
Min
8mA Min
-8mA Min
15pF
10mS
100nS
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
2
An internal pullup resistor from pin 1 to V
DD
allows active output if pin 1 is left open.
All specifications subject to change without notice.
Rev. 6/1/04
All dimensions are in millimeters.
• ENABLE / DISABLE FUNCTION
INH (Pin 1)
OUTPUT (Pin 8)
OPEN
2
ACTIVE
'1' Level V
ih
≥
2.2 V
ACTIVE
'0' Level V
il
≤
0.8 V
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1(239) 693.0099 FAX +1 (239) 693.1554
http://www.foxonline.com
EMEA
United Kingdom Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 FAX +852.2854.4282
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
