Continuously Variable - Flat with Frequency Types
Specifications
Frequency Ranges:
800 MHz - 12.4 GHz as noted
Attenuation Range:
0 - 30 dB as noted
Flattness:
see table
Impedance:
50 Ohms
VSWR:
1.50 max
Insertion Loss:
0.5 dB max
Power:
5 Watts average
Peak Power:
3 Kilowatts Peak
Operating Temperature Range:
-65 to +125C
Resetability:
0.1 dB max
Finish:
Connectors are Passivated Stainless Steel
Housings are Irridited Aluminum
Variable Attenuators
Midwest Microwave's series of Miniature Continuously Variable Attenuators
were designed to meet the most stringent environmental conditions. The Flat
with Frequency Types are useful for applications where a specific level of
attenuation is required over a frequency band and reasonable attenuation
flattness over the frequency band is necessary. The units are available in a
Standard simple locking type configuration, a Panel mount type with a knob,
or a Turns-counting dial type, also panel mounted, for refrence setting or if
calibration is desired. SMA connector configurations are standard, however
Type N or TNC connector configurations are also available (see note below).
S = Standard Locking Nut Type
Flat with Frequency Models
Freq Range
(GHz)
0.80 - 0.90
0.89 - 0.96
1.2 - 1.4
2.0 - 4.0
Atten Range
(dB)
10
10
15
10
20
Flattness
(+ dB)
1.7
1.5
1.5
1.0
1.5*
0.5
1.0
0.5
1.0
2.0
Model Number
CVA-FS89-10-SMA-05
CVA-FS90-15-SMA-05
CVA-FS91-15-SMA-05
CVA-FS92-10-SMA-05
CVA-FS92-20-SMA-05
CVA-FS93-10-SMA-05
CVA-FS93-20-SMA-05
CVA-FS94-10-SMA-05
CVA-FS94-20-SMA-05
CVA-FS94-30-SMA-05
.45
(11.4)
.88
(22.4)
.84
(21.3)
4.0 - 8.0
10
20
P = Panel Mounting Type
8.0 - 12.4
10
20
30
*Note:Flattness is +/- 1.5 dB @ 0 - 13 dB and +/- 2.25 dB @ 13 - 20 dB
Notes:
1. To designate a Panel type option, subsitute "P" for "S" in the Model No..
2. To designate a Turns-Counting Dial option, subsitute "T" for "S" in the Model No..
3. To designate Type N or TNC connectors, subsitute "NNN" or "TNC" for "SMA" in the Model No.
T = Turns Counting Panel Mounting Type
24
