L-1387QMP/1GYW: DescriptionDual Color LED, Yellow/green, Diffused White, 3.4mm, ROHS COMPLIANT PACKAGE-2; CategoryLED optoelectronic/LED photoelectric; File Size116KB，4 Pages; ManufacturerKingbright; Websitehttp://www.us.kingbright.com; Environmental Compliance

Download Datasheet Parametric View All

L-1387QMP/1GYW Overview

Dual Color LED, Yellow/green, Diffused White, 3.4mm, ROHS COMPLIANT PACKAGE-2

L-1387QMP/1GYW Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Kingbright
package instruction	ROHS COMPLIANT PACKAGE-2
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	HIGH RELIABILITY
color	YELLOW/GREEN
Configuration	COMMON BIPOLAR TERMINAL, 2 ELEMENTS
Maximum forward current	0.03 A
Lens type	DIFFUSED WHITE
Nominal luminous intensity	10.0/20.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	DUAL COLOR LED
total height	4.8 mm
method of packing	TAPE AND REEL
peak wavelength	590/565 nm
shape	ROUND
size	3.4 mm
surface mount	YES
Terminal pitch	2.54 mm
perspective	60 deg

Preview

Download Datasheet

View All

3.4mm SURFACE MOUNT LED

P/N: L-1387QMP/1GYW

GREEN / YELLOW

Features

SURFACE MOUNT TYPE.

I.C. COMPATIBLE.

BLACK CASE ENHANCES CONTRAST.

WIDE VIEWING ANGLE.

HIGH RELIABILITY LIFE MEASURED IN YEARS.

PACKAGE: 1000PCS / REEL.

HOUSING MATERIAL: PPA

HIGH TEMPERATURE RESISTANT HOUSING.

UL RATING : 94V-0.

RoHS COMPLIANT.

Description

The Green source color devices are made with Gallium

Phosphide Green Light Emitting Diode.

The Yellow source color devices are made with Gallium

Arsenide Phosphide on Gallium Phosphide Yellow

Light Emitting Diode.

Package Dimensions

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

±0.25(0.01")

unless otherwise noted.

3.Specifications are subject to change without notice.

SPEC NO: DSAD0323

APPROVED: J. Lu

REV NO: V.4

CHECKED: Allen Liu

DATE: NOV/14/2005

DRAWN: W.J.ZHU

PAGE: 1 OF 4
