Product – Specification
TYPE CHR SERIES
SPECIFICATIONS
UNITS
Rated Power @ 70 °C
Resistance Range Min
Max
Tolerance
Code letter
Selection Series
Temperature Coefficient
Limiting Element Voltage
Maximum Overload Voltage
Operating Temperature Range
Climatic Category
Resistance to Soldering Heat
Long Term Stability
High Temperature Loading
Short Term Overload
Watts
Ohms
%
ppm/°C
Volts
Volts
°C
1M0
50M
1
2
F
G
16
th
December 2003
ISSUE 2
0603
0.031
1M0
150G
10
20
K
M
1M0
50M
1
2
F G
0805
1206
2512
%
0.0625
0.125
1.0
1M0
1M0
1M0
1M0
150G
50M
150G
150G
5
5
10
20
1
2
5
10
20
5
10
J
J
K
M
F G J
K
M
J
K
E24 series
100
See Graph
100
See Graph
100
See Graph
See Graph
50
75
150
300
100
150
300
500
-55 to +125
55/125/21
(1% & 2% = ±0.5% /5%, 10% & 20% = ±1%)
260°C ±5°C 10 +1/-0 seconds
±0.5%
At normal temperature and humidity for 1,000 hours
(1% & 2% = ±0.5% /5%, 10% & 20% = ±1%)
DC15V, 1.5 hours ON, 0.5 hours OFF, 1,000 hours at 70°C
(1% & 2% = ±0.5% /5%, 10% & 20% = ±1%)
Test for 5 seconds using maximum overload voltage.
20
M
DIMENSIONS
STYLE
0603
0805
1206
2512
L
1.6 ± 0.1
2.0 ± 0.2
3.2 ± 0.2
6.4 ± 0.2
W
0.8 ± 0.1
1.25 ± 0.2
1.6 ± 0.2
3.2 ± 0.2
t
0.45 ± 0.1
0.5 ± 0.1
0.55 ± 0.1
0.55 ± 0.1
a
0.2 ± 0.1
0.4 ± 0.2
0.5 ± 0.3
0.5 ± 0.3
b
0.3 ± 0.1
0.4 ± 0.2
0.5 ± 0.3
0.5 ± 0.3
DERATING CURVE
TEMPERATURE COEFFICIENT
VOLTAGE COEFFICIENT
Telephone Tyco Passive Product Support Team ++ 44 (0) 1793 572484
Website – passives.tycoelectronics.com
Email – passivesales@tycoelectronics.com
Page 2 of 4
Product – Specification
TYPE CHR SERIES
PACKAGING
16
th
December 2003
ISSUE 2
8mm Wide Tape
12mm Wide Tape
0603
Tape Width
A
tol
B
tol
t1 max.
t2 nom.
Reel qty.
8
1.15
± 0.15
1.9
± 0.2
0.8
0.6
5000
0805
8
1.65
± 0.15
2.5
± 0.2
1.0
0.8
5000
1206
8
2.0
± 0.15
3.6
± 0.2
1.0
0.8
5000
2512
12
3.6
± 0.1
6.9
± 0.2
-
1.1
2000
MOUNTING
The resistors are suitable for processing on automatic placement equipment.
MARKING
These resistors are not marked with the resistance value.
Telephone Tyco Passive Product Support Team ++ 44 (0) 1793 572484
Website – passives.tycoelectronics.com
Email – passivesales@tycoelectronics.com
Page 3 of 4
Product – Specification
TYPE CHR SERIES
PERFORMANCE CHARACTERISTICS
The evaluation of the performance characteristics is carried out with reference to IEC specifications
QC 400 000 and QC 400 600.
16
th
December 2003
ISSUE 2
TEST REF
4.23
4.24
4.25.1
4.25.3
TEST REF
4.13
4.16
4.18
4.19
4.22
Long Term Tests ±(1% + 0.05 ohm)
Climatic sequence
Damp heat, steady state
Endurance at 70 °C
Endurance at 125 °C
Short Term Tests ±(1% + 0.05 ohm)
Overload
Robustness of terminations
Resistance to soldering heat
Rapid change of temperature
Vibration
STORAGE
Unopened reels should be stored within a temperature range of +5°C to +25°C, separated from any dust, chemicals and solvent
based materials. Non-adherence to this procedure could affect the solderability of this product.
HOW TO ORDER
Orders for these components should include the following information: -
Type, tolerance code letter and value
e.g. CHR0603 J 220M
