F-213-1
TM
TMMH–125–04–L–DV–EP
EXTENDED LIFE PRODUCT
(2,00 mm) .0787"
TMMH SERIES
TMMH–122–04–T–DV–LC
10 year Mixed Flowing Gas with 30µ" Gold
Call Samtec for maximum cycles
FLEXIBLE SMT HEADER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?TMMH
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to +105°C with Tin;
-55°C to +125°C with Gold
Voltage Rating:
500 VAC mated with SQW
RoHS Compliant:
Yes
CURRENT RATING
(PER CONTACT)
AMBIENT
TEMP
20°C
40°C
60°C
95°C
Mated with
ESQT
5.8A
5.1A
4.5A
2.9A
SQW
5A
4.6A
4A
2.6A
–EL OPTION
–EC OPTION
–TR OPTION
Mates with:
CLT, SQT, SQW, ESQT,
TLE, SMM, MMS, TCSD
FLEX SHROUD
OPTIONS
–ES OPTION
–M OPTION
–A OPTION
–EP OPTION
ALSO AVAILABLE
Through-
Hole
2 mm Shunt
Specify
2SN–BK–G
for
2 mm shunt with Gold plating.
(1,95)
.077
(4,45)
.175
(3,99)
.157
TMMH
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD STYLE
from chart
PLATING
OPTION
6 POSITIONS (2x3) POWERED
Processing:
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10 mm) .004" max
–F
= Gold flash
on post,
Matte Tin on tail
03 thru 50
OPTION
–ES
Z
LEAD
STYLE
–01
–04
–05
A
MATES
WITH
–L
= 10µ" (0,25 µm)
Gold on post,
Matte Tin on tail
(2,92)
.115
(4,70)
– EC
.185
(6,10)
–EP & –EPC
.240
(4,45)
–EL & –EBC
.175
SQT, SQW,
(3,20) ESQT, TLE,
.126 SMM, MMS,
TCSD
(1,91)
CLT
.075
(1,65)
.065
–T
= Matte Tin
Note:
Other Gold plating
options available.
Contact Samtec.
No. of positions x (2,00) .0787 +
Z
(2,00)
.0787
02
100
(1,40)
.055
(6,35)
.250
(1,09)
.043
DIA
01
99
–A
No. of positions x (2,00) .0787
(2,00)
.0787
(2,51)
.099
(4,00)
.157
A
(10,16)
.400
x
(6,35)
.250
(0,64)
.025
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
(0,51)
.020
SQ
(2,00) .0787
(Shrouded options removed for clarity)
(7,04)
.277
–M
(1,42)
.056
– LC
WWW.SAMTEC.COM
TMMH–116–04–F–DV–EL
TMMH–110–01–T–DV–A
TMMH–125–01–L–DV
TMMH–120–04–T–DV
TMMH–110–04–F–DV
Optional end shrouds
with board lock
(2,00 mm)
.0787"
Surface mount
(2,00 mm)
.0787"
(2,00 mm) .0787"
Optional alignment pins
or locking clips
DV
FLEX SHROUD OPTIONS
OTHER OPTIONS
All Flex Shroud options require 9 pins/row minimum
(For board-to-board interfaces. Will not mate with TCSD)
–“XXX”
= Polarized Position. Specify position of omitted pin
–ES
LEAD
STYLE
X
Y
= End Shroud
(For best cost also see TSH Series)
–A
= Alignment Pin
(3 positions minimum)
(N/A with -LC)
–01
(5,84) (4,45)
.230 .175
–04 &
(4,50) (3,02)
–05
.177 .119
(4,00)
.157
–EC
= End Shroud with Locking Clip
(For best cost also see TSH Series)
(Manual placement required)
–LC
= Locking Clip
(5 positions minimum)
(N/A with -A)
(Manual placement required)
–EP
= End Shroud with Guide Post
(1,32)
.052
(1,41)
.056
– EBC
–EL
= End Shroud with Board Lock
(Boards are positively locked and cannot be unmated)
–M
= Pick & Place Pad
(5 positions minimum)
(N/A with -T plating)
–EBC
= End Shroud with Board Lock and Locking Clip
(Boards are positively locked and cannot be unmated)
–TR
= Tape & Reel Packaging
(36 positions maximum)
(Flex Shroud options not available
except –ES, –EP & –EL)
–EPC
(1,17)
.046
(3,20)
.126
X
= End Shroud with Guide Post and Locking Clip
(Manual placement required)
Y
TAPE & RE
(1,91)
.075
DIA
(2,44)
.096
X
(1,32)
.052
(1,32)
.052
arges.
No tooling ch e lesser of
der is th
Minimum orantity or 125 pieces.
a full reel quantity above minimum.
Order any qu sign, manufacture.
In-house de turn-around.
Quick
tions
for specifica
Call Samtecring information.
and orde
EL AVAILA
BILITY
– EL
– ES
– EC
– EP
– EPC
WWW.SAMTEC.COM
