REVISION B
C3
CBTH-XXX-XX-X-D-XX
(No OF POS. x .01969[.5000]) + .1968[5.000] REF
No OF POSITIONS
***
030, 050, 060, 090,
120, 150
(PER ROW)
LEAD STYLE -02 ONLY: 030 - 180
MULTIPLES OF 10
LEAD STYLE
DO NOT
SCALE FROM
THIS PRINT
(No OF POSITIONS -1) x .01969[.5000]
.1082 2.749 REF
01
.0080 0.203
REF
.1550 3.937 REF
02
.2350 5.969
REF
.0470 1.194 REF
BTH-XXX-XX-D
*** = 50 POS. ONLY AVAILABLE FOR -01
AND -02 LEAD STYLE (REF ASP-65267-02)
.055 1.40
.0100 0.254 REF
.0375 0.952
REF
R
.0375 0.953 REF
.0350 0.889 REF
(No OF POS. x .01969[.5000]) + .1368[3.475] REF
-A: ALIGNMENT PIN OPTION SHOWN
NOTES:
O
S
B
O
"A"
"B" REF
"A"
LC-08-TM-01
2 MAX SWAY
(TYP)
-LC: LOCKING CLIP OPTION SHOWN
BTH-XXX-XX-D-A
.XX: .01[.3]
.XXX: .005 [.13]
.XXXX: .0020 [.051]
MATERIAL:
SEE TABLE 2
E
L
C2
-01: .1680[4.267]
-02: .2861[7.264]
(030 -180 POSITIONS AVAILABLE)
-03: .4042[10.267]
-04: .6000[15.240]
-05: .7180[18.237]
-06: .8360[21.234]
-09: .5224[13.269]
T-1SXX-XX-X-C
E
T
C1
OPTION
-A: ALIGNMENT PINS
(USE BTH-XXX-XX-D-A FOR
STYLES -01 & -02)(FOR STYLES
-03 THRU -09, SEE TABLE 4 &
FIG. 4, SHEET 3)
-LC: LOCKING CLIPS
(USE LC-08-TM-01)
-K: POLYAMIDE FILM
(USE K-500-300, SEE FIG. 2)
(AVAILABLE ON STYLES -01
THRU -04 & -09 ONLY)
ROW SPECIFICATION
-D: DOUBLE (USE BTH-XXX-XX-D
& BTHH-XXX-XX-D)
PLATING SPECIFICATION
-C: ELECTRO-POLISHED SELECTIVE
(USE T-1SXX-XX-C)
"A"
.003[.08]
.001[.03]
(SEE NOTE 3)
.0370 0.940 REF
.2800 7.112
.0375 0.953 REF
SECTION "A"-"A"
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
ANGLES
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: 6 OZ. FOR STYLES -01 & -02
8 OZ. FOR STYLES -03 THRU -09
3. MAXIMUM VARIANCE OF .002[.05].
4. LEAD STYLES -03 THRU -09: TOP BODY (BTH)
CANNOT HAVE -A OPTION.
2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DO NOT SCALE DRAWING
SHEET SCALE: 1.875:1
DESCRIPTION:
INSULATOR: BLACK LCP
FLAMMABILITY RATING: UL 94V-O
TERMINAL: PHOS BRONZE
F:\DWG\MISC\MKTG\CBTH-XXX-XX-X-D-XX-MKT.SLDDRW
.5mm DOUBLE ROW TERMINAL ASSEMBLY
DWG. NO.
CBTH-XXX-XX-X-D-XX
10/08/07
SHEET
1
OF
3
BY:
B. PERRY
REVISION B
-K: POLYAMIDE FILM PAD OPTION
[USE K-500-300]
"R" REF
"S"
.021 0.52
FIG. 2
.276 7.01
"T"
NOTE: "R" = (No OF POSITIONS x .01969[.5000]) + .1968[5.000]
"S" = (("R" - .276[7.01]) / 2) .020[.51]
(PARTS TO HAVE POSITIOIN #01 LOADED IN SAME DIRECTION AS ARROW)
[STYLES -01 & -02]
[STYLES -03, -04, & -09]
[STYLE -05]
[STYLE -06]
PACKAGING VIEW
TUBE: PT-1-24-01-78
PLUG: TP-03
TUBE: PT-1-24-01-98
