BUK7Y25-80E

8 May 2013

N-channel 80 V, 25 mΩ standard level MOSFET in LFPAK56

Product data sheet

1. General description

Standard level N-channel MOSFET in an LFPAK56 (Power SO8) package using

TrenchMOS technology. This product has been designed and qualified to AEC Q101

standard for use in high performance automotive applications.

2. Features and benefits

•

Q101 compliant

Repetitive avalanche rated

Suitable for thermally demanding environments due to 175 °C rating

True standard level gate with V

GS(th)

rating of greater than 1 V at 175 °C

3. Applications

•

12 V, 24 V and 48 V Automotive systems

Motors, lamps and solenoid control

Transmission control

Ultra high performance power switching

4. Quick reference data

Table 1.

Symbol

tot

DSon

Quick reference data

Parameter

drain-source voltage

drain current

total power dissipation

Conditions

≥ 25 °C; T

≤ 175 °C

= 10 V; T

= 25 °C;

Fig. 1

= 25 °C;

Fig. 2

= 10 V; I

= 10 A; T

= 25 °C;

Fig. 11

= 10 V; I

= 10 A; V

= 64 V;

= 25 °C;

Fig. 13; Fig. 14

8.2

Min

Typ

Max

Unit

Static characteristics

drain-source on-state

resistance

16.7

mΩ

Dynamic characteristics

gate-drain charge
