MC33201, MC33202,
MC33204, NCV33202,
NCV33204
Low Voltage, Rail-to-Rail
Operational Amplifiers
The MC33201/2/4 family of operational amplifiers provide
rail−to−rail operation on both the input and output. The inputs can be
driven as high as 200 mV beyond the supply rails without phase
reversal on the outputs, and the output can swing within 50 mV of each
rail. This rail−to−rail operation enables the user to make full use of the
supply voltage range available. It is designed to work at very low
supply voltages (± 0.9 V) yet can operate with a supply of up to +12 V
and ground. Output current boosting techniques provide a high output
current capability while keeping the drain current of the amplifier to a
minimum. Also, the combination of low noise and distortion with a
high slew rate and drive capability make this an ideal amplifier for
audio applications.
Features
http://onsemi.com
PDIP−8
P, VP SUFFIX
CASE 626
1
SOIC−8
D, VD SUFFIX
CASE 751
8
8
1
•
Low Voltage, Single Supply Operation
•
•
•
•
•
•
•
•
•
•
8
1
Micro8]
DM SUFFIX
CASE 846A
(+1.8 V and Ground to +12 V and Ground)
Input Voltage Range Includes both Supply Rails
Output Voltage Swings within 50 mV of both Rails
No Phase Reversal on the Output for Over−driven Input Signals
High Output Current (I
SC
= 80 mA, Typ)
Low Supply Current (I
D
= 0.9 mA, Typ)
600
W
Output Drive Capability
Extended Operating Temperature Ranges
(−40° to +105°C and
−55°
to +125°C)
Typical Gain Bandwidth Product = 2.2 MHz
NCV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements
Pb−Free Packages are Available
PDIP−14
P, VP SUFFIX
CASE 646
14
1
SOIC−14
D, VD SUFFIX
CASE 751A
14
1
14
1
TSSOP−14
DTB SUFFIX
CASE 948G
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 10 of this data sheet.
DEVICE MARKING INFORMATION
See general marking information in the device marking
section on page 12 of this data sheet.
©
Semiconductor Components Industries, LLC, 2011
December, 2011
−
Rev. 16
1
Publication Order Number:
MC33201/D
MC33201, MC33202, MC33204, NCV33202, NCV33204
PIN CONNECTIONS
MC33201
All Case Styles
NC 1
2
Inputs
3
V
EE
4
6
5
Output
NC
Inputs 2
8
7
NC
V
CC
Output 1 1
2
Inputs 1
3
1
4
MC33204
All Case Styles
14 Output 4
13
12
11
10
2
3
Inputs 4
V
EE
Inputs 3
Output 3
V
CC
4
5
6
(Top View)
MC33202
All Case Styles
Output 1 1
2
Inputs 1
3
V
EE
4
2
1
9
8
Output 2 7
(Top View)
V
CC
Output 2
8
7
6
Inputs 2
5
(Top View)
V
CC
V
CC
V
CC
V
in -
V
EE
V
out
V
in +
V
CC
V
EE
This device contains 70 active transistors (each amplifier).
Figure 1. Circuit Schematic
