ZTX689BSTOA: DescriptionSmall Signal Bipolar Transistor, 3A I(C), 20V V(BR)CEO, 1-Element, NPN, Silicon, TO-92 COMPATIBLE, E-LINE PACKAGE-3; CategoryDiscrete semiconductor The transistor; File Size90KB，3 Pages; ManufacturerDiodes Incorporated

Download Datasheet Parametric Compare View All

ZTX689BSTOA Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ZTX689BSTOA	-	-	View	Buy Now

ZTX689BSTOA Overview

Small Signal Bipolar Transistor, 3A I(C), 20V V(BR)CEO, 1-Element, NPN, Silicon, TO-92 COMPATIBLE, E-LINE PACKAGE-3

ZTX689BSTOA Parametric

Parameter Name	Attribute value
Maker	Diodes Incorporated
Parts packaging code	TO-92
package instruction	IN-LINE, R-PSIP-W3
Contacts	3
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum collector current (IC)	3 A
Collector-emitter maximum voltage	20 V
Configuration	SINGLE
Minimum DC current gain (hFE)	150
JESD-30 code	R-PSIP-W3
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	NPN
Certification status	Not Qualified
surface mount	NO
Terminal surface	MATTE TIN
Terminal form	WIRE
Terminal location	SINGLE
Maximum time at peak reflow temperature	40
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	150 MHz

Preview

Download Datasheet

View All

NPN SILICON PLANAR MEDIUM POWER

HIGH GAIN TRANSISTOR

ISSUE 1 MAY 94

FEATURES

* 20 Volt V

CEO

* Gain of 400 at I

=2 Amps

* Very low saturation voltage

APPLICATIONS

* Darlington replacement

* Flash gun convertors

* Battery powered circuits

* Motor drivers

ZTX689B

E-Line

TO92 Compatible

ABSOLUTE MAXIMUM RATINGS.

PARAMETER

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Peak Pulse Current

Continuous Collector Current

Practical Power Dissipation*

Power Dissipation

at T

amb

=25°C

derate above 25°C

SYMBOL

CBO

CEO

EBO

totp

tot

stg

VALUE

1.5

5.7

-55 to +200

UNIT

mW/°C

°C

Operating and Storage Temperature Range

*The power which can be dissipated assuming the device is mounted in a typical manner on a

P.C.B. with copper equal to 1 inch square minimum

ELECTRICAL CHARACTERISTICS (at T

amb

= 25°C)

PARAMETER

Collector-Base Breakdown

Voltage

Collector-Emitter Breakdown

Voltage

Emitter-Base Breakdown

Voltage

Collector Cut-Off Current

Emitter Cut-Off Current

Collector-Emitter Saturation

Voltage

Base-Emitter

Saturation Voltage

Base-Emitter

Turn-On Voltage

Static Forward Current

Transfer Ratio

SYMBOL

(BR)CBO

(BR)CEO

(BR)EBO

CBO

EBO

CE(sat)

BE(sat)

BE(on)

500

400

150

3-235

MIN.

0.1

0.5

0.9

TYP.

MAX.

UNIT

CONDITIONS.

=100

=10mA*

=100

=16V

=4V

=0.1A, I

=0.5mA*

=2A, I

=10mA*

=1A, I

=10mA*

IC=1A, V

=2V*

=0.1A, V

=2V*

=2A, V

=2V*

=6A, V

=2V*
