Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
1W max.
0.125W max.
Coaxial
ZFSC-2-11+
ZFSC-2-11
50Ω
10 to 2000 MHz
Features
• very wideband, 10 to 2000 MHz
• low insertion loss, 0.3 dB typ.
• high isolation, 30 dB typ.
• excellent amplitude unbalance, 0.1 dB typ.
• excellent phase unbalance, 0.5 deg. typ.
• rugged shielded case
BNC version shown
CASE STYLE: K18
Connectors Model
BNC
ZFSC-2-11(+)
SMA
ZFSC-2-11-S(+)
N-TYPE
ZFSC-2-11-N(+)
BRACKET (OPTION "B")
Price
$64.95
$69.95
$69.95
$2.50
Qty.
(1-9)
(1-9)
(1-9)
(1+)
Coaxial Connections
SUMPORT
PORT 1
PORT 2
3
1
2
Applications
• cellular
• GPS
• satellite distribution
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Splitter Electrical Specifications
Outline Drawing
FREQ.
RANGE
(MHz)
L
f
L
-f
U
10-2000
ISOLATION
(dB)
M
U
INSERTION LOSS (dB)
ABOVE 3.0 dB
L
M
U
PHASE
UNBALANCE
(Degrees)
L
Max.
1
M
Max.
2
U
Max.
4
AMPLITUDE
UNBALANCE
(dB)
L
Max.
0.20
M
Max.
0.30
U
Max.
0.50
Typ. Min Typ. Min Typ. Min
14
10
16
14
20
15
Typ. Max. Typ. Max. Typ. Max.
1.2
1.5
1.2
1.5
1.0
2.0
L = low range [f
L
to 10 f
L
]
M = mid range [10 f
L
to f
U
/2]
U= upper range [f
U
/2 to f
U
]
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
10.00
28.00
46.00
73.00
100.00
370.00
730.00
1050.00
1250.00
1450.00
1550.00
1650.00
1750.00
1850.00
2000.00
3.51
3.50
3.60
3.45
3.56
3.52
3.37
3.35
3.57
3.41
3.35
3.42
3.56
3.51
3.60
Amplitude
Unbalance
(dB)
0.00
0.00
0.00
0.00
0.00
0.00
0.01
0.02
0.01
0.01
0.01
0.00
0.01
0.00
0.02
Isolation
(dB)
Phase
Unbalance
(deg.)
0.02
0.02
0.01
0.01
0.02
0.00
0.10
0.14
0.17
0.20
0.10
0.12
0.06
0.03
0.19
VSWR
S
VSWR
1
VSWR
2
S-2
3.52
3.51
3.60
3.44
3.55
3.52
3.36
3.33
3.56
3.39
3.33
3.43
3.56
3.51
3.63
17.25
18.77
18.67
18.16
18.04
18.12
19.20
20.86
21.62
21.59
21.13
20.40
19.45
18.24
16.53
2.02
2.02
2.02
2.02
2.02
1.97
1.82
1.65
1.53
1.43
1.39
1.34
1.28
1.23
1.14
ZFSC-2-11
ISOLATION
25
23
21
19
17
15
1.55
1.55
1.54
1.52
1.51
1.50
1.55
1.60
1.63
1.63
1.62
1.60
1.57
1.54
1.47
1.55
1.55
1.54
1.52
1.51
1.50
1.55
1.61
1.64
1.65
1.65
1.63
1.61
1.58
1.53
Outline Dimensions (
inch
)
mm
A
1.25
31.75
B
1.25
31.75
C
.75
19.05
D
.63
16.00
E
.38
9.65
F
1.00
25.40
G
.125
3.18
H
1.000
25.40
J
--
--
K
--
--
L
.125
3.18
M
1.688
42.88
N
2.18
55.37
P
.75
19.05
Q
wt
.07 grams
70.0
1.78
For option B with N-type connectors, dimension "C" increases to 0.94 inches.
4.0
INSERTION LOSS (dB)
ZFSC-2-11
INSERTION LOSS
S-1(dB)
S-2(dB)
3.6
3.4
3.2
3.0
0
400
800
1200
1600
2000
FREQUENCY (MHz)
ISOLATION (dB)
3.8
0
400
800
1200
1600
2000
FREQUENCY (MHz)
2.4
2.2
2.0
VSWR
1.8
1.6
1.4
1.2
1.0
0
400
#S-VSWR
ZFSC-2-11
VSWR
#1-VSWR
electrical schematic
#2-VSWR
800
1200
1600
2000
REV. A
M98898
ZFSC-2-11
HY/TD/CP
060915
FREQUENCY (MHz)
