Product Facts
I
Connector system designed
for exclusive use with I/O
and power circuits in the
power and control boards
of heavy electric systems
and FA equipment, process
computers, FA computers,
PCs, NCs, servodrivers,
servomotors, inverters,
switching power supplies,
etc.
Consists of wire-side
connector and board-side
connector
Diverse housings are avail-
able to meet most specific
applications
With contacts standardized,
the tool types used can be
reduced
I
Termination can be
automated and field
maintenance simplified
As contacts can be crimped,
connector quality is
maintained
Standardization of contacts
leads to easier manage-
ment of inventory
To help prevent human
errors in termination a com-
mon identification mark is
on hand tools and contacts
Housing color and design
are coordinated
Need more information?
