PMAD-1-23-A-L-8 datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Optical fiber> PMAD-1-23-A-L-8

PMAD-1-23-A-L-8: DescriptionAdd/Drop Mux/Demux, LC/SPC Connector; CategoryWireless rf/communication Optical fiber; File Size261KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

PMAD-1-23-A-L-8 Overview

Add/Drop Mux/Demux, LC/SPC Connector

PMAD-1-23-A-L-8 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknown
channel spacing	100 GHz
Connection Type	LC/SPC CONNECTOR
Fiber optic equipment types	ADD/DROP MUX/DEMUX
Fiber type	PM PANDA FIBER
Maximum operating temperature	65 °C
Minimum operating temperature
Nominal operating wavelength	1559 nm

Preview

Download Datasheet

View All

DWDM

Polarization Maintaining DWDM Add/ Drop

Parameter

Center Wavelength (λc)

Channel Pass Band

Insertion Loss (Express Channel)

Insertion Loss (Add/Drop Channel)

Pass Band Ripple

Polarization Extinction Ratio (Common to

Add/Drop)

Polarization Extinction Ratio (Common to

Express)

Adjacent Channel Isolation

Non-Adjacent Channel Isolation

Directivity

Return Loss

Maximum Power

Operating Temperature

Storage Temperature

Package

Dimensions

Light Duty (B)

Medium Duty (L)

100 GHz

ITU Grid

≥ λc ± 0.11 nm

≤ 0.5 dB

≤ 1.0 dB

≤ 0.5 dB

≥ 17 dB

≥ 25 dB

≥ 40 dB

≥ 50 dB

≥ 45 dB

300 mW

0° C to + 65° C

200 GHz

≥ λc ± 0.25 nm

≤ 0.8 dB

- 40° C ~ + 85° C

5.5 mm () x 35 mm (L)

5.5 mm () x 40 mm (L)

Note1: All values specified are without connectors.

Note2: Higher performance specifications are available upon request.

Note3: Fiber type: PM Panda 250 μm fiber.

P M A D

Channel Spacing

1: 100 GHz

2: 200 GHz

ITU Channel#

e.g 23: 1558.98 nm

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

Fiber Length

Pigtail Style

A: 1 meter

(=Package style)

B: 1.5 meter B: bare fiber

S: Special

L: 900 μm loose tube

www.lightel.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
