SURFACE MOUNT
SMT electrolytic
Small can sizes
Long life grade (up to 2000 hours @ 105°C)
New expanded CV range
Designed for automatic mounting and reflow soldering
SECTION 1
0.3 Max
W
ELECTROLYTIC 105˚C REDUCED SIZE DVJR
SPECIFICATION
Item
Category Temperature Range (°C)
Tolerance of Rated Capacity (%)
Leakage Current (µA)
Tangent of Loss Angle (tan∂)
Characteristics at high and low
temperature
Performance
–50 to +105
± 20
Less than 0.01CV or 3 whichever is larger (after 2min) C: rated capacitance (µF)
Rated Voltage (V)
6.3
10
16
25
35
50
tan∂ (max)
0.30 0.24 0.22 0.16 0.13 0.12
Rated Voltage (V)
6.3
10
16
25
35
50
Impedance Ratio (max)
4
3
2
2
2
2
Z–25°C / Z+20°C
Z–40°C / Z+20°C
8
5
4
3
3
3
Test Time*
2000 hours
Leakage Current
The initial specified value or less
Percentage of Capacitance Change Within 20% of initial value
Tangent of Loss Angle
200% or less of the initial specified value
Dø
Test Time: 1000 hours: other items are the same as those for endurance. JIS C5101-1
JIS C5101-1, –18 1998 (IEC600384-1 1992, -18 1993)
0.3 Max
Endurance (105°C)
(Applied Ripple Current)
Shelf Life (85°C)
Applicable Standards
* at the end of part number on page 00 denotes 1000 hours
L
OUTLINE DRAWING
Dø
B
D
Ø
4
W
L
A
L
5.3 +/- 0.2
5.3 +/- 0.2
5.3 +/- 0.2
6.5 +/- 0.3
10 +/- 0.5
10 +/- 0.5
A
4.3
5.3
6.6
8.4
8.4
10.4
B
4.3
5.3
6.6
8.4
8.4
10.4
I
2.0
2.3
2.7
3.4
3.0
3.3
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
P
1.0
1.5
2.0
2.3
3.1
4.7
5
6.3
8
8
10
I
B
P
I
COEFFICIENT OF FREQUENCY FOR RATED RIPPLE CURRENT
Frequency (Hz)/
Rated Voltage
6.3 to 16
25 to 35
50 to 63
I
P
100
50-60
A
120
1
1
1
1
1k
1.15
1.25
1.35
1.35
10k - 100k
1.25
1.40
1.50
1.50
I
0.8
0.8
0.8
0.7
ORDERING INFORMATION
DVJR
Series
47
Capacitance
35
Voltage
LF
Lead Free
76
