BRM-1040-2-FB4.3 Overview

Photo IC,

BRM-1040-2-FB4.3 Parametric

Parameter NameAttribute value
MakerBRIGHT
Reach Compliance Codeunknown
BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BRM-1040-2-FB4.3
INFRARED RECEIVER MODULE
Description
1. The BRM-1040-2-FB4.3 is miniaturized infrared
receivers for remote control and other applications
requiring improved ambient light rejection.
2. The separate PIN diode and preamplifier IC are
assembled on a single lead frame.
3. The epoxy package contains a special IR filter.
4. This module has excellent performance even in
disturbed ambient light applications and provides
protection against uncontrolled output pulses.
1.45(.057)
3.85(.152)
Package Dimensions:
Features
4.5(.177)
7.4(.292)
13.65(.538)
10.2(.402)
90°
1.
2.
3.
4.
5.
6.
7.
Photo detector and preamplifier in one package .
Internal filter for PCM frequency.
High immunity against ambient light.
Improved shielding against electric field disturbance.
5.0V supply voltage; low power consumption.
TTL and CMOS compatibility.
Suitable transmission code :NEC code,RC5 code.
NOTES:
1
2
6.40(.213)
9.7(.382)
4.3(.016)
3
0.5(.020)
2.54(.10)
14.3±0.5(.56)
Applications:
1. It can be used for TVs、VTRs、audio equipment
air conditioners、 car stereo radio、toys、 home
computers and all other equipment requiring remote
control.
1.All dimensions are in millimeters (inches).
2.Tolerance is ±0.10mm (0.004’’) unless otherwise specified.
3.Specifications are subject to change without notice.
BLOCK DIAGRAM
2.4(.095)
Vcc
Vout
Limiter
B.P.F
PD
ABLC
Demodulator
Preamp
Amp
Integrator
Comparator
GND
REV: 1.0 Page: 1of 4
