MSWSE-010-15S
Silicon PIN Diode Switch Element
1
2
0402
(Molded Platic DFN Package)
Features
• SMALL SIZE (40 mils X 24 mils)
• Broadband performance up to 3.0 GHz
• Supports up to 10 watts power
• Low insertion loss 0.15 dB typical up to 3.0 GHz
• Cost effective choice for switch applications
Description
The MSWSE-010-15S is a PIN diode switch element
designed for medium incident power applications, up
to 10 W C.W. It has low insertion loss and medium
isolation below 3.0 GHz.
Maximum Ratings
RATING
V
R
I
F
θ
JC
T
J
T
STG
T
SOLDER
LIMITS
200
200
35
+175
-55 to +150
+260
o
C per JEDEC J-STD-20C
o
UNITS
V
mA
C/W
o
o
C
C
Electrical Specifications,
T
A
= +25 °C
SYMBOL
V
BR
V
F
C
J
C
T
R
S
t
W
IL
IRL
Iso
I
R
= 10
μA
I
F
= 50 mA
V
R
= -50 V
V
R
= -50 V
I
F
= 30 mA
I
F
= 100 mA
I
F
= 10 mA
I
R
= 6 mA
F = 1 MHz
F = 1 MHz
F = 500 MHz
F = 500 MHz
measured at 50%
F < 1.0 GHz
F < 2.0 GHz
F < 1.0 GHz
F < 2.0 GHz
F < 1.0 GHz
F < 2.0 GHz
TEST CONDITIONS
MIN
200
–
–
–
–
–
–
–
–
–
25
–
15
–
TYPICAL
–
870
0.13
0.17
0.8
0.6
650
40
0.05
0.10
30
25
20
15
MAX
–
950
–
0.22
1.0
0.8
900
–
–
0.25
–
–
–
–
UNITS
V
mV
pF
pF
Ω
Ω
ns
μm
dB
dB
dB
dB
dB
dB
I-Layer
I
F
= 50 mA
I
F
= 50 mA
V
R
= 50 V
METELICS
Revision Date: 6/17/2013
1
METELICS
Package Outline (0402) and PCB Layout
MSWSE-010-015S
Dimensions: inches [mm]
Finish: 300 micro inches matte Tin, annealed 1 hour at 150° C
Electrical Schematic
1
2
Junction Temperature vs Pin
Mounted on Heatsink 25°C Amb 1.3 GHz
80
60.00
70
50.00
60
Forced Air / Fan
Fan
25° C Lead Temp (Liquid Nitrogen)
Natural Convection
Pin, W
Pin (W)
40.00
50
40
30.00
30
20.00
20
Free Air Flow
10.00
10
0
0.00
0
0
20
20
40
40
60
60
80
80
100
100
120
120
140
140
160
160
180
Junction
Temperature
Junction
Temperature, °C
(°C)
408-737-8181 • 888-641-SEMI (7364) • metelics-sales@aeroflex.com • www.aeroflex.com/metelics
Revision Date: 6/17/2013
3
MSWSE-010-15S
METELICS
Aeroflex / Metelics Inc.
Aeroflex Microelectronic Solutions
975 Stewart Drive
Sunnyvale, CA 94085
TEL: 408-737-8181
Sales
888-641-SEMI (7364)
metelics-sales@aeroflex.com
ISO 9001: 2008 certified companies
54 Grenier Field Road
Londonderry, NH 03053
TEL: 603-641-3800
www.aeroflex.com/Microwave www.aeroflex.com/Metelics
Aeroflex / Metelics, Inc. reserves the right to make changes to any products and services
herein at any time without notice. Consult Aeroflex or an authorized sales representative to
verify that the information in this data sheet is current before using this product. Aeroflex
does not assume any responsibility or liability arising out of the application or use of any
product or service described herein, except as expressly agreed to in writing by Aeroflex;
nor does the purchase, lease, or use of a product or service from Aeroflex convey a license
under any patent rights, copyrights, trademark rights, or any other of the intellectual rights
of Aeroflex or of third parties.
Copyright 2013 Aeroflex / Metelics. All rights reserved.
Our passion for performance is defined by three
attributes represented by these three icons:
solution-minded, performance-driven and customer-focused.
Revision Date: 6/17/2013
4
