DC COMPONENTS CO., LTD.
R
UF3A
THRU
UF3K
RECTIFIER SPECIALISTS
TECHNICAL SPECIFICATIONS OF SURFACE MOUNT ULTRA FAST RECTIFIER
VOLTAGE RANGE - 50 to 800 Volts
CURRENT - 3.0 Amperes
FEATURES
* ldeal for surface mounted applications
* Low leakage current
* Glass passivated junction
SMC ( DO-214AB )
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
*Terminals: Solder plated, solderable per
MIL-STD-750, Method 2026
* Polarity: As marked
* Mounting position: Any
* Weight: 0.24 gram
.128(3.25)
.108(2.75)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current T
A
= 75 C
Peak Forward Surge Current I
FM
(surge): 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Forward Voltage at 3.0A DC
Maximum DC Reverse Current at
Rated DC Blocking Voltage
Maximum Reverse Recovery Time (Note 3)
Typical Thermal Resistance (Note 2)
Typical Junction Capacitance (Note 1)
Operating and Storage Temperature Range
@T
A
= 25
o
C
@T
A
= 125
o
C
o
UF3A
50
35
50
UF3B
100
70
100
UF3D
200
140
200
3.0
100
UF3G
400
280
400
UF3J
600
420
600
UF3K
800
560
800
UNITS
Volts
Volts
Volts
Amps
Amps
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
trr
RθJL
C
J
T
J
, T
STG
1.0
10
300
50
10
60
1.4
1.7
Volts
uAmps
nSec
0
C/ W
pF
0
-65 to + 175
C
NOTES : 1. Measured at 1.0 MHz and applied average voltage of 4.0VDC
2. Thermal Resistance (Junction to Ambient), 0.2x0.2in
2
(5X5mm
2
)copper pads to each terminal.
3. Test Conditions: IF=0.5A, IR=1.0A, IRR=0.25A.
330
